MIC3111C-0152W-LF3 RJ45 Modular Jack LPJK0071AONL 1000BT Integrated Magnetic
Price:
Supportive&Competitive
MOQ:
50/500/1000
Delivery Time:
Stock
Brand:
LINK-PP
Product Description
MIC3111C-0152W-LF3 RJ45 Modular Jack LPJK0071AONL 1000BT Integrated Magnetic
|
Part Number
|
Made In China
|
Manufacturer
|
Description |
|
MIC3111C-0152W-LF3
|
LPJK0071AONL
|
LINK-PP
|
Modular Jack With Integrated Magnetics With LEDS
|
|
|
|||
|
Series
|
Connector Type
|
Applications
|
Mounting Type
|
|
Connectors, Interconnects
|
LINK-PP Rj45
|
1000 Mbps
|
Thru-Hole
|
|
|
|||
|
Orientation
|
Termination
|
LED Color
|
Shielding
|
|
90° Angle (Right)
|
Solder
|
O,G/Y
|
Shielded
|
|
NOTES: 1. Designed to support application,such as SOHO(ADSL modems), LAN-on-Motherboard(LOM),hub and Switches. 2. Meets IEEE 802.3 specification 3. Connector Materials: Housing: Thermoplastic UL94V-0 Contact / Shield : Cooper alloy Shield plating : Nickel Contact plating: Gold 6 micro-inches min.In contact area. 4. Wave solder tip temperature : 265℃ Max Wave solder tip temperature Time : 5 Sec Max
|
|||
| Part Number | MIC3111C-0152W-LF3 | Height(mm) | 13.50 |
| Cross Compatible | LPJK0071AONL | Length(mm) | 32.50 |
| Manufacturer | LINK-PP | Width(mm) | 16.60 |
| Speed | 1000 Base-T | Number of Port | 1 |
