XPJG-PL4TI-10F6-YG1-ELH Magnetic 1x1 R-j45 LPJ4049GDNL 8P8C Shield Right Angle

• 1x 10/100 Mbps RJ45 Switching Ports
• Rj45 Connector with 10/100 Base-t Integrated Magnetics For PoE Application
• IEEE 802.3 10/100BASE-T
• Rj45 Right Angle PCB Connector
• LPJ4049GDNL : -40℃～85℃
• RJ-45 connector integrated with Filter

NOTES:

1.Designed to support application,such as SOHO(ADSLmodems),LAN-on- Motherboard(LOM),hub and     Switches.

2.Meets IEEE 802.3 specification

3.Connector Materials:

Housing: Thermoplastic PBT+30%G.F UL94V-0

Contact: Phosphor Bonze C5210R-EH Thickness=0.35mm

Pins: Brass C2680R-H Thickness=0.35mm

Shield: SUS 201-1/2H Thickness=0.2mm

Contact plating: Gold 6 micro-inches min.In contact area.

4.Wave solder tip temperature: 265℃ Max, 5 Sec Max

5.UL Certification: File Number E484635
