H6101FNLT SMD Gigabit Magnetic POE+ Transformer LP6080NL
H6101FNLT ELECTRICAL CHARACTERISTICS AT +25℃
| MEETS IEEE 802.3 SPECIFICATION | |
| PARAMETER | SPECIFICATIONS |
| TURNS RATIO | 1.00士2% |
| POLARITY | PER SCHEMATIC |
| INSERTION LOSS |
-1.2 dB MAX @ 100KHz -0.2-0.002*1.4 dB MAX @ 1-125KHz |
| RETURN LOSS |
-16 dB MIN @ 1-40KHz -10+20*LOG 10(f/80 MHz)dB MIN @ 40-100KHz |
| INDUCTANCE(OCL) | 350uH MIN |
| CROSSTALK, ADJACENT CHANNELS |
-50 dB MIN @ 1MHz -55+22*LOG10(f/10)dB MIN @ 10-100MHz |
| COMMON MODE REJECTION RATIO |
-50 dB MIN @ 2MHz -15+20*LOG10(f/200)dB MIN @ 30-200MHz |
| DC RESISTANCE,1/2 WINDING | 0.30 OHMS TYP |
| DC RESISTANCE BALANCE | ±0.05 OHMS MAX(CENTER TAP SYMMETRY) |
| DC CURRENT/VOLTAGE RATING-PSE PINS | 600 mA MIN @ 57V(CONTINUOUS) |
| INPUT-OUTPUT ISOLATION | 1500 VRMS MIN @60 SECONDS |
LP6080NL (Cross H6101FNLT) 1000Base-T Transformer Drawing
