SR4 100G QSFP28 Transceiver 100M ON OM4 For Ethernet And Data Center

SR4 100G QSFP28 Transceiver 100M ON OM4 For Ethernet And Data Center

Description:


An optical fiber ribbon cable with an MTP/MPO connector can be plugged into the QSFP28 module receptacle. Proper alignment is ensured by the guide pins inside the receptacle. The cable usually cannot be twisted for proper channel to channel alignment. Electrical connection is achieved through an MSA-compliant 38-pin edge type connector.

The module operates by a single +3.3V power supply. LVCMOS/LVTTL global control signals, such as Module Present, Reset, Interrupt and Low Power Mode, are available with the modules. A 2-wire serial interface is available to send and receive more complex control signals, and to receive digital diagnostic information. Individual channels can be addressed and unused channels can be shut down for maximum
design flexibility.

The product is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP28 Multi-Source Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference. The module offers very high functionality and feature integration, accessible via a two-wire serial interface.

Product Details:

Features:

1. 100G Ethernet aggregate optical line rate of 103.125 Gbps (4 x 25.78125 Gbps I/O)
2. 4 Tx + 4 Rx parallel channels for transmission on 8 parallel MMF fibers with up to 100m reach
3. Operating case temperature range from 0ºC to 70ºC
4. Power dissipation < 2.5 W (SFF Power Class 3)
5. Integrated VCSEL & PIN-based optical engine
6. SFF-8472 Digital Diagnostic Monitoring support
7. Hot pluggable 38-pin electrical interface

Ordering Information:

• AQSFP28-100G-SR4     QSFP28 SR4 100m optical transceiver with full real-time

                                                  digital diagnostic monitoring and pull tab
