17 inch Stainless Steel IP68 Wall Mount Table Standing Touch Screen Waterproof Outdoor Digital Signage
17 inch Stainless Steel IP68 Wall Mount Table Standing Touch Screen Waterproof Outdoor Digital Signage
Quick details of stainless steel outdoor waterproof touch screen display :
1. 17inch 4:3 panel.
2. 1500nits high brigtness.
3. 10 point PCAP touch screen.
4. Android or Windows system.
5. With RS232 port.
6. To be installed on the wall or stand on the table.
Description of stainless steel outdoor waterproof touch screen display :
This outdoor IP68 waterproof touch screen display can be installed on the wall or stand on the table, with 304 stainless steel material and air cooling fans inside to protect 1500nits high brightness panel with resolution of 1280*1024 which is 4:3 square screen, we also have many other screen size on sale. System can be with Android or Windows, be with RS232 port as requested by our customer. The stand is rotatable so viewing angle is adjustable, besides, it support logo printing on the stainless steel shell, logo color can be at your request.
Specification of stainless steel outdoor waterproof touch screen display :
| Resolution | 1280*1024 | |||||
| Display area | 337*270 mm | |||||
| Glass | AR minus reflection glass 6 mm, light transmittance 97%, reflectivity is less than 3%, laminating,explosion-proof membrane surface | |||||
| Brightness | 1500cd/m2, Brightness: has brightness sensor, auto-adjustment as per different daylight to lower power consumption | |||||
| Number of Color | 16.7M | |||||
| Response time | 4 (ms) approximately | |||||
| Contrast | 1000:1 | |||||
| View angle | 178°/178°(H/V) | |||||
| Life Time | > 50000 (hours) | |||||
| Power Supply | AC 110V~240V,50/60HZ | |||||
| Electronic part | Electricity leaking protection, lightning protection | |||||
| Shell Material | 304 Stainless steel with IP68 waterproof | |||||
| Wall mount bracket | As per attached picture | |||||
| Heat Dissipation | Air-cooling fans built-in, with patent fully intelligent temprature control technology including heating function | |||||
| Logo printing | On top left and top right corner | |||||
| Speaker | 10W*2 | |||||
| Power Consumption | 40W, Industrial-grade power board, brightness auto-adjustment to lower power consumption | |||||
| Touch screen | 10-point PCAP touch screen | |||||
| Color | Black or silver | |||||
| Photo formats | JPEG ,BMP ,GIF ,PNG | |||||
| Audio formats | MP3,WAV,WMA | |||||
| Video formats | MP4,AVI,DIVX,XVID,VOB,DAT,MPG,MPEG,RM,RMVB,MKV,MOV,HDMOV,M4V, | |||||
| Bare dimension | TBC | |||||
| Wooden box packing size | TBC | |||||
| Normal Working Temperature | -40 to 55 Celsius degree | |||||
| The operating system | Android 11.0 | |||||
| CPU | RK3568 | |||||
| RAM | DDR4 2G | |||||
| Memory | 16G | |||||
| Interface | out*1, USB-OTG*1, USB*1, RJ45*1, SD card*1 | |||||
| The operating system | Windows 10 | |||||
| CPU | I3, I5, I7 | |||||
| Memory | DDR3 4G, 8G | |||||
| SSD | 128G or 256G | |||||
| Interface | HDMI out*1,USB *4 ,LAN *1, VGA*1 | |||||
Application of stainless steel outdoor waterproof touch screen display :
This outdoor portable touch screen kiosk can be put in outdoor dining table for people to check information, also can be put in outdoor table with way finding software, all ports can be covered so it can be put into water.
