3D Touch Screen Digital Signage video wall / indoor 1080P wall mount advertising player
3D Touch Screen Digital Signage video wall / indoor 1080P wall mount advertising player
| Model | MD-550 |
| Panel brand | LG or Sumsung |
| Unit dimensions | 55” |
| Panel type | TFT-LCD |
| Brightness | 800cd/ m2 |
| Contrast | 1200:1 |
| Optimal resolution | 1980×1080 |
| Aspect ratio | 16:9 |
| Display color | 16.7M |
| Response time | 8ms |
| Pixel pitch | 0.53025 (H) ×0.53025mm (V) |
| Viewing Angle | 178º (H)/178º(V) |
| Lamp life | 50000 (minimum) hours |
| Operating temperature | 0~50℃ |
| Humidity | 10%~80% |
| Surface treatment | Matte (Haze 5.5%), |
| Display area | 1214×684mm (horizontal*vertical) |
| Dimensions | 1215.2× 686 mm (horizontal*vertical) |
| Dimensions | 58.53 (Max.) mm (thickness) |
| Physical seam | 5.5mm |
| Basic functions | M rows × N columns, multi-unit splicing, full-screen display, split-screen display, any combination display (multi-channel signal), PIP signal cross screen roaming, superimposing and zooming |
| Image splicing controller (optional) | 1. Multi-layer cross screen roaming and superimposing, scaling of all windows in any proportion and any size in full range; 2. Support intelligent split of single, four, six, nine and sixteen screens, built-in HD mixing matrix |
| Input and output | |
| High definition multimedia interface | 1-channel |
| Digital video interface | DVI-D 1-channel |
| D-Sub interface | VGA 1-channel |
| Composite video input | BNC 2-channel |
| Composite video output | BNC 2-channel |
| Control interface | RJ45 (RS-232 protocol) |
| Video | |
| Video format | PAL/NTSC/SECAM |
| Compatible input | 480P, 576P, 720P, 1080P |
| 3D noise reduction | Yes |
| Video noise reduction | Yes |
| Power supply | |
| Voltage input | AC100V~240V 50/60HZ |
| Power loss | ≤220W |
| Standby power | ≤3W |
| Mounting | |
| Wall-mounted, floor-standing enclosure (optional) | |
LCD-DID Industrial HD&High-brightness narrow edge LCD.
Narrow Edge Design: Minimum 10mm.
High Resolution Ratio: 1920*1080
High-brightness: 700cd/sqm
Super wide visual angle:178(H)/178(V)
Digital information display with LCD-DID Industrial HD&High-brightness narrow edge LCD.
Built-in splicing module, Support splice function,support Creating one window(PIP) across the screen,roaming service,scaling,PIP Support matrix joint control.
Unique DNX motion supplement image processing technology, Dynamic image without motion
trail,Splicing image processing RS-232(RJ-45)loop-circuit input/output.,Input by remote control with wire,mobile receiver head.
