4K Industrial Grade DID LCD Video Wall 55inch 2*2 Sound Media Player TV Wall
1.8Mm LCD Screen Wall 700cd / m2 , Industrial Grade DID Video Wall 2*2 Sound Media Player
Ultra Narrow Bezel 1.8mm LCD Screen Wall 2*2 LCD Video Wall Industrial Grade DID Video Wall Sound Media Player
Feature Ultra-thin Bezel design to deliver maximum visual impact for all Digital Signage and Conference Collaboration Applications. With energy-saving LED Technology that enables 24hr a day operation, and Auto Standby for Image Burn Protection offer premium, reliable performance to meet all your commercial application demands.
Video wall communicate more effectively every moment of the day, unlimited size option giving visitors a more vivid expereience in reception area, enhance company and brand impression.
| Specification | MD-550 | Panel Size | 55"LED | ||
| Panel brand | Original Samsung/LG A level | ||||
| Aspect Ratio | 16:9 | ||||
| Visual Angle | Horizontal 178/Vertical178 | ||||
| Brightness | 700cd/sqm | ||||
| Bezel | 1.8 mm | ||||
| Back light | LED backlight | ||||
| Contract Ratio | 3500:1 | ||||
| Resolution Ratio | 1920*1080 | ||||
| Color Components | 10Bits | ||||
| Response Time | 8ms | ||||
| Power Consumption | 120W/150W | ||||
| Standby power consumption | 10W | ||||
| Power Supply | Input:AC110-220V-50/60Hz | ||||
| Life of Panel | 60000Hours | ||||
| Panel Display Area | 1209.6*680.4mm | ||||
| Outline Dimension | 1211.4*682.2*53.3mm | ||||
| Pixel Pitch | 0.630*0.630 | ||||
| Port | 2*BNC(video in/out), 1*VGA in, 1*DVI in,1* in, 1*RS232 in, 2*RS232 out, 1*Debug ISR | ||||
| VGA/DVI Resolution Ratio | 640*480,800*600,1024*768,1280*1024,1600*1200,1920*1080 | ||||
| Resolution Ratio | 480I,480P,576I,720P,1080I,1080P | ||||
| Split Screen/PIP Mode | Two signals image or PIP | ||||
| Splice Function | Multiscreen Splice Function(image processing Function) | ||||
| Carton Packing | 2pc/carton, carton size: 135*34*81cm, G.W.:58kg | ||||
| Wooden box packing | 7pc/wooden box, wooden box size:140*128*98cm, G.W.:281kg | ||||
| Bracket carton packing(for 7pc system) | 146*34*25cm, G.W.:33kg | ||||
Applicable Fields:
Business Organizations: Supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places: Subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;
Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course.
Why choose us:
1. 13-years professional manufacturing experience only in digital signage field.
2. LCD display projects from 8" to 108' in various brightness can be tailor-made according to your specific requirements.
3. Rich experience in OEM and ODM projects in more than 10 years.
4. Less MOQ can meet your various requirements.
5. Fast delivery time, sample needs 10-15days, bulk needs 15-20days, have stock of standard item.
6. Flexible Payment term: support T/T, L/C, Westunion, Paypal.
7. Shipments: Internation express, airfreight, oceanfreight.
8. Warranty: 1-year warranty, lifetime maintenance.
