TFT Full HD Standing Hall Outdoor Digital Signage Totem 1920*1080 Resolution
Price:
Negotiable
MOQ:
2pcs
Delivery Time:
Negotiable
Brand:
Genevision
Product Description
TFT Full HD Standing Hall Outdoor Digital Signage Totem 1920*1080 Resolution
Specifications:
| Technical Parameter for LCD Panel | Panel Size | 70inch real color LCD screen |
| Aspect Ratio | 16:9 | |
| Active Area | 1549.4mm(H) x 871.5mm(V) | |
| Max. Resolution | 1920x 1080 | |
| Dot Pitch | 0.807mm(H) x 0.807mm(W) | |
| Number of Color | 16.7M | |
| Brightness | 600cd/m2 | |
| Contrast Ratio | 2000:1 | |
| Responsive Time | 8ms | |
| Panel Life | above 50000 hours | |
| Storage Medium | Flash memory card | 2gb to 36gb for the capacity |
| Support Ad files | Video formats | MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD: DAT/MPG1) |
| Audio formats | MP3 | |
| Photo formats | JPG | |
| OSD Language | English, Chinese, French, German, Italian, Spanish,Arabic | |
| Audio output | stereo L/R, 5W*2, 8Ω | |
| Power supply | AC 110V - 240V, 50/60HZ | |
| Storage Temperature | -7 to 65 Celsius degree | |
| Normal Working Temperature | -5 to 65 Celsius degree | |
The Technical Parameter for infrared touchscreen Panel
| Touch Max Resolution | 4096×4096 |
| Transparency | > 90%, Up to 100% |
| Scanning Speed | >50Scans/S |
| Response Speed | <12ms |
| Touch Type | Horizontal Multi Dot Touch Screen (Vertical way is optional) |
| Touch precision | 0.625mm |
| Minimum Touch object | ≥5mm |
| Touch Intensity | Over 60,000,000 Single Point Touch |
| Operation System | DOS, WINDOWS9X/ME/2000/XP/2003/VISTA, LINUX |
| perating Voltage | DC 5V ±5% |
| Power Supply | Keyboard Serial Interface |
| Power | <1W (Current<200mA) |
| Communication | RS-232 Interface Port, USB Port |
| Vandal-Proof | Steel Ball (Diameter 63.5mm 1040g Weight) drop from 1040mm, No break |
| Temperature Operating | -41°C ~70°C Temperature Storage: -50°C ~85°C |
| Altitude | 3000m |
| Noise | None |
| Life Time | >10 Year |
Competitive Advantage:
Interactive experience for the machine,which attracts the attention from people.
Tag:
Touch LCD AD player,Touch LCD Media Player,Touch LCD AD Board,Touch LCD monitor.
