Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701
Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701
|
A16.0701Inverted Fluorescent Microscope |
|
|
Optical System |
Infinite Optical System |
|
Head |
Siedentopf binocular viewing head,inclined at 45°,360° Rotatable, Interpupillary 48-75mm |
|
Eyepiece |
Ф30 Wide Field Eyepiece WF10×/22,Eyepiece Tube Diameter 30mm |
|
Objective |
Infinite Plan Achromatic Objective 4x//0.10 WD=22 |
|
Infinite LWD Plan Achromatic Phase Objective 10x/0.25 WD=6 |
|
|
Infinite LWD Plan Achromatic Phase Objective 20x//0.4 WD=3.1 |
|
|
Infinite LWD Plan Achromatic Objective 40x/0.55 WD=2.2 |
|
|
Focusing |
Coaxial coarse and fine adjustment, fine division 2μm,Moving Range up 4.5mm down 4.5mm |
|
Nosepiece |
Backward Quintuple Nosepiece |
|
Condenser |
ELWD Condenser NA0.3,LWD72mm(without Condenser 150mm) |
|
Centering Telescope |
Centering Telescope(φ30mm) |
|
Phase Annulus |
10x,20x,40x Phase Annulus Plate(Adjustable) |
|
Stage |
Plain Stage 230×170 |
|
Glasse Insert |
|
|
Auxiliary Stage |
|
|
Terasaki Holder |
|
|
Petri Dish Holderφ38 |
|
|
Petri Dish Holderφ54 |
|
|
Attachable Mechanical Stage,X,Y Coaxial Control,Moving Rang 80×120mm |
|
|
Illumination |
6V/30W Halogen Lamp, Brightness Adjustable |
|
Flurenscent Attachment |
Epi-Fluorenscent Illumination |
|
B,G |
|
|
Blue,Green and ground glass ,Diameter 45mm |
|
