Industrial Cryogenic Oxygen Nitrogen Gas Plant / Liquid Nitrogen Generator System
Industrial Cryogenic Oxygen Nitrogen Gas Plant / Liquid Nitrogen Generator System
Quick Details:
Condition: new
Place of origin: China(mainland)
Brand name: UIG
Model number: KZO, KZON TYPE
Production capacity:50/60/80/100 m3/hour
Power :76-138 KW(Shaft power)
Voltage:380v,400V,440V
Certification: ISO 9001:2000
Warranty:1 year
Life:20 years with proper maintenance
After-sales service provided: Engineers available to service plants overseas
Usage: Industrial and medical (oxygen, nitrogen) .
UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % AND NITROGEN 99.999%
Specifications:
Air separation plants(pure nitrogen and high pure nitrogen)
|
Model contents |
KDN- 400/15Y |
KDN- 800/40Y |
KDN- 1000-40Y |
KDN- 1600-60Y |
KDN- 2000-80Y |
KDN- 2400-100Y |
KDN- 3000-120Y |
KDN- 4500/180Y |
|
|
N2 flow |
Nm³/h |
500 |
800 |
1000 |
1600 |
2000 |
2400 |
3000 |
4500 |
|
LN2 flow |
L/h |
15 |
30 |
40 |
60 |
80 |
100 |
120 |
180 |
|
N2 purity |
Ppm(o2) |
≤3 |
≤3 |
≤3 |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
|
N2 pressure |
Mpa |
as the user requires |
|||||||
|
Start-up time |
hour |
~12 |
~12 |
~14 |
~16 |
~16 |
~18 |
~18 |
~20 |
|
Operating period |
year |
≥1 |
≥1 |
≥2 |
≥2 |
≥2 |
≥2 |
≥2 |
≥2 |
Description:
You may find that the connection between individual machines & equipments is high pressure flexible tube, this is one of the advanced features for this plant as designed. It will definitely save installation period on site.
Compressed the liquid oxygen through liquid pump. So the oxygen can be used in hospital.
The connection pipes are high pressure soft pipe, easy connect and separate,The time of installation and testing is not more than 30 days.
Adopted screw compressor (main machine imported from world famous company). Keep the plant normal work long time,Easy operate and maintenance.
Air cooling type is adopted for whole set of plant, there is no cooling water required.
Need very small area (Land Area 40㎡,Factory Area 90㎡),.
Skid mounted type air separation plant, connected by high pressure flexible pipe between individual machines/equipments ,
Plant features
1) This air separation plant adopts cryogenic separation process. Oxygen is obtained by inner compression, so it can be both for medical & industrial usage and to be filled into cylinder.
2) Whole set of plant adopts skid mount type and connected with high-pressure hose between individual machines/equipments. So, it no need any foundation required to save investment cost for civil construction and shorten installation period accordingly.
3) Cooling mode of plant adopts air cooling for whole set of plant, no cooling water system required so it also save investment cost for the owner.
4) This plant can be shifted to any second plant to operate because of its no fixed foundation feature. So it is a mobile type plant.
Applications:
we supplied to many countries (Russia, Kazakhstan, Tajikistan, India, Bangladesh, Thailand, Philippines, North Korea, Mongolia, Equatorial Guinea, Botswana, Zambia, Angola, Tanzania) .
Process:
Air→ Air compressor → Pre-cooler → Purifier →Rectification column and Turbo-expander →liquid oxygen tank or liquid nitrogen tank
Competitive Advantage:
Higher economic efficiency, good quality, lower transportation cost, better performance price, safety and convenience.
Small size air separation unit,Small size nitrogen plant,Small size liquid nitrogen plant,Small size air separation equipment,Small size air separation plant,Small size nitrogen machine
