Back - Up Battery IP 54 Linear Actuator Control Boxes Hospital Bed Accessories
Back-Up Battery IP 54 Linear Actuator Control Boxes Hospital Bed Accessories
Features:
- Can control 1 - 6 linear actuators
- Can match with customized controllers
- EN60601 and UL60601-1, -2
- Back-up battery (option)
- IP grade : IP 54
Specifications
| Model | YA-JCB35E |
| Number of Actuator Outputs | 1-6 outputs |
| Input Voltage: (VAC) | 110 / 230 |
| Output Voltage (VDC) | 24/29VDC |
| Transformer Power (Watter) | 86 / 150/200/360 |
| Duty cycle | 10%, max 2 min. Continuous Use |
| Overload protection |
For All Channels (Single-extra protected or combined-extra protected), Option |
| Hand/Foot Control Plugs | DIN 8 / DIN13 Straight Plug |
| Actuator Plugs | DIN 4 / DIN5 Straight Plug |
| Power Plug | Option |
| Color | Black or Grey |
| Fuse | Can be changed from outer side |
| IP Grade | IP54 |
| Cable Length | 3m |
| Ambient Temperature | +5 degree ~ +40 degree |
| Standard | UL60602-2 / CE |
| Option Features | Back-Up Battery, 1.3Ah/24V, Charger Build-In |
| Customized Intelligent Function with microchips build-in option | |
|
Battery and Customized function togthe
|
The YA-JB35E has the following benefits:
Unique safety concept which prevents unintended actuator movement
Possibility of special software to achieve desired functionality, movement pattern and safety level in the application
Possibility of add on accessories such as light, wireless hand control or nurse call via hand control and Gateway
