Plastic Extrusion Process Plastic Extrusion Line With Single Screw Extruder
Plastic Profile Extrusion Making Machine , Plastic Wood Profile Production Line
Quick detail:
1. The pvc profile production machine can produce PE , PP or PVC and wood profile products.These products are mainly applied for making pallets , packing cases , floors , wall decoration mateials and other wide applications. The wood powder or plant fiber can be put up tp max , 50-75%. This machine can produce the PP , PE , PVC , ABS , PS and etc.
2. We are expert manufacturer of PVC marble profile making machine and we can supply you turnkey solution including machines, installation, raw material, training staff, good after-sales etc.
Our machine adopt ABB inverter, SIMENS motor to make sure the good quality of machine.
Description:
1. PVC marble profile making machine is used to produce different types of PVC marble profiles, it can be used in the wall decoration, to make the wall looks like real marble decoration.
2. The Plastic Profile production line according to the different requirements of customers and cross-sectional shape of the mold, you can choose the most suitable twin-screw extruder , and equipped with the appropriate vacuum form-ing . Cuttting and other auxiliary traction.
3. A pre-heating feeder is mounted on the top of the extruder which extracts the humidity from the wood powder , so that the feeding section of the extruder can be filled with enough material and the plastification effect will be better.
4. Special and well designed screw enables the raw material to be evently stay in the extruder. The screws and barrel are bi-metallic treated , nore wearable and anti-corrosion.
Applications:
The pvc profile production line is suitable to produce the PP, PE, PVC + wood composite products, the WPC products are strong and durable, both have the advantages of plastic and wood products, at the same time, they overcomes the shortages of plastic products that is easily got deformed, and the wood products can easily get corrosion, damaged by worms, short service life, etc. They are popularly used as packing case and wood-polymer tray; flooring panel, indoor and outdoor decoration, plank flooring, pavilion and chair in park, etc. The amount of wood power or fibers can reach to 50-70%.
Specifications:
| Model | SJZ51/105 | SJZ55/100 | SJZ65/132 | SJZ80/156 | SJZ92/188 |
| Screw diameter(mm) | 51/105 | 55/100 | 65/132 | 80/156 | 92/188 |
| Quantity of screw | 2 | 2 | 2 | 2 | 2 |
| Max. rotation speed of screw(r/min) | 40 | 38 | 38 | 37 | 36 |
| Effective length of screw(mm) | 1200 | 1200 | 1440 | 1800 | 2500 |
| Main motor power(kw) | 18.5 | 22 | 37 | 55 | 110 |
| Productuion capacity(kg/h) | 100 | 150 | 250 | 400 | 750 |
| Center height(mm) | 1000 | 1000 | 1000 | 1100 | 1200 |
Competitive Advantage:
24 hours services;
Overseas installation;
Free operation training and technology formula transfer;
Old machine update;
Spare parts and maintenance with reasonable cost price.
