China Sale PE Plastic Pipe Production Line , Water Suppling PVC / PP / PE Pipe Extrusion Machine

Quick detail

1. Special single screw extruder for polyolefin , having high extruding velocity and effective plasticization. Separation mixing screw specialized for polyolefin. Specially designed 2-3 co-extruding die,  reasonbable channel , smooth outside and inside wall , and little internal stress. Producing pipe limit 20-160mm , manufacture velocity up to 15m/min. May be used to produce HDPE silicon core tube , Ordinary PP-R , PE , PEX and PE-RT pipes.

2. Equipment List:
1. SJ65x33 Single Screw Extruder
2. Extrusion Mould
3. Vacuum Calibrating Tank
4. Cooling Tank
5. Haul-off Machine(Tractor)
6. Cutting Machine
7. Stacker or Winder
8. Automatic Feeder and Dryer


Description:

1. PE / PPR pipes are used to build hot and cold water systems,including central heating systems. Building heating system,including floor,wall and radiant heating systems. Drinking water supply systems. In the central (concentration) air - conditioning systems.

2. The main machine adopts screws specially used for polyolefin. It possesses features of high production, good plasticization and stable extruding.

It is equipped with automatic vacuum appending machines and automatic constant temperature drying hopper.

3. Die heads of helical type and basket type are perfect for polyolefin, and can help to produce sound melting pressure, and improve the plasticization capacity. Meanwhile, stable material-flow and pressure grade can be guaranteed.

Advanced vacuum calibrating method improves the cleanliness and hardness of surface. Reasonable high-speed sprinkling cooling water tank guarantees the pipe quality and high speed stable extruding.

4. Caterpillar of the hauling machine adopts anti-abrasion alloy material, which realizes stable traction, wide frequency adjustment range and long lifespan.

New generation auto dust-free cutting blade realizes smooth cutting surface, high precision and low noise

Main technical parameter of HDPE pipe production line/ PE Pipe extrusion line

If you want more details of our HDPE pipe machine/ HDPE pipe making machine, please let us know!

Application:

It is mainly used to produce PE water pipe, gas pipe, drain pipe and so on. This set is also suitable for the production of crosslinked PE pipes and other olefine products. Our company can provide you with detailed ingredients and complete manufacture line.

Why choose us:

1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
