Fully Automatic Conical Twin Screw Extruder With CE ISO9901 Certificate
High Quality Conical Twin Screw Extruder / Plastic Twin Screw Extruder With CE ISO9901 Certificate
Quick detail
1. SJZ series conical twin- screw extruder especially used for extrusion PVC powder, it has advantages as good mixing, large output, working steady , long service life time etc. equipped with series mold and auxiliary machine, it can produce various PVC pipes, profiles, sheets, plates, bars and it also can be used for pelletizing.
2. SJZ series conical twin- screw extruder system has applied special computer control. According to customers requirements, most reasonable structure of conical twin screw can be made so as to achieve best plasticity performance and material quality.
Description:
1. Conical twin-screw extruder is widely used in the field of PVC profile, PVC pipe, PVC panel/board/sheet, PVC pelletizing, Wood PVC compound product extrusion, etc. It has advantages such as forced extruding, high quality, wide adaptability, long working life, low shearing speed, hard decomposition, good compounding& plasticization effect.
2. The SJZ series conical twin screw extruder is a kind of special equipment for extruding PVC powder. With different molds and auxiliary machines, it can produces all kinds of plastic pipe, window and door, ceiling profile, and granulates, etc. Our twin screw extruders are made of Siemens Beide main motor, ABB inverter, Omron temperature controller, and Chinese famous brand gearbox, etc. The screw and barrel is under nitriding process for longer using life.
3. Temperature controller is Japanese RKC, contactor is SIEMENS. The gear and the axis components of speed reducer used high strength alloy steel material . Screw structure designed specifically for customer need. Nitriding depth is 0.5—0.6mm, hardness is HV740—940, surface roughness Ra≤0.8um.
Conical twin screw extruder Main Technical Standards:
| model | SJSZ51 | SJSZ55 | SJSZ65 | SJSZ80 | SJSZ92 |
| Screw diameter | 51/105 | 55/110 | 65/132 | 80/156 | 92/188 |
| Screw speed | 1-40 | 1-38 | 1-38 | 1-37 | 1-36 |
| Center height | 1050 | 1150 | 1050 | 1050 | 1100 |
| The motor power | 18.5 | 22 | 37 | 55 | 90 |
| Output(KG/H) | 80-100 | 100-150 | 150-250 | 250-380 | 380-700 |
| Net Weight(KG) | 3000 | 3500 | 4000 | 5500 | 8000 |
| L*W*H(m) | 3.6*1.1*2.1 | 3.6*1.1*2.1 | 4.2*1.5*2.4 | 4.7*1.5*2.4 | 6*1.6*2.5 |
| Screw direction | Opposite and outer | ||||
Our competetive advantages:
Equipment warranty
1. About the equipment, Middle tech promised the good quality of 12 month.
2. during the warranty, no purposely and artificially damage change the damaged part, we will free
maintenance and technical services.
3. Over 12 months, Buyer's needs to pay the producing cost of the worn part, and life-long supply the part of equipment and freely device
