3.5 Ton Lithium Battery Forklift 3-3.8 Tons Electric Forklift Crane Counterweight Electric Forklifts
3.5 Ton Lithium Battery Forklift 3-3.8tons Electric Forklift Crane Counterbalanced Forklift
Description:
- Green environmental protection, zero emission, low noise;
- Reliable structure: Longgong E series 3-3.8 ton internal combustion vehicle body is used, and the structure is firm and reliable
- Excellent performance: the lifting/tilting, driving and climbing performance are exactly the same as those of internal combustion vehicles;
- High-voltage control system: using 153.6V automotive-grade voltage, high reliability and low energy loss;
- Strong battery life: standard 165Ah lithium battery, the battery life can reach 6-8 hours;
- High charging efficiency: 10-100% power can be achieved, and it can be fully charged in 1.5 hours;
- High protection level: integrated integrated electrical system, the protection level reaches IP65;
- Wide field of view: The wide field of vision gantry of the internal combustion vehicle is used to improve the safety of stacking operations;
- High degree of generalization: the commonality with Longgong E series 3-3.8 tons internal combustion vehicle parts is as high as 95%;
Specification:
| model | unit | CPD-35EWL | |
| Rated load | Kg | 3500 | |
| Load center distance | mm | 500 | |
| Maximum lift height | mm | 3000 | |
| free lift height | mm | 170 | |
| Fork size | mm | 1070×125×50 | |
| Gantry inclination (front/rear) | deg | 6-12 | |
| Dimensions | Overall length (to fork back) | mm | 2830 |
| Overall width | mm | 1240 | |
| Safety rack height | mm | 2130 | |
| Minimum turning radius | mm | 2540 | |
| front overhang | mm | 493 | |
| Track (front wheel) | mm | 1000 | |
| Wheelbase (rear wheel) | mm | 980 | |
| Minimum ground clearance | mm | 130 | |
| wheelbase | mm | 1760 | |
| Minimum right angle stacking channel width | mm | 4260 | |
| speed | Walking (empty/full) | Km/h | 20/20 (Power Mode) |
| 15/15 (standard mode) | |||
| 10/10 (energy saving mode) | |||
| Lifting (no load/full load) | mm/s | 420/400 | |
| Descent (no load/full load) | ≥300/≤600 | ||
| Tilt (no load/full load) | °/s | ‘8/8 | |
| Maximum grade (no load/full load) | % | 20/20 | |
| dead weight | Kg | 4520 | |
| Travel motor | Kw | 18 | |
| Lifting motor | 20 | ||
| battery | V/Ah | 153.6/230 | |
| Working tank capacity | L | 60 | |
| work pressure | Mpa | 18.5 | |
Forklifts up to 3 tons can also work in cabins, train cars and containers.
After the fork is replaced with various attachments, the counterbalanced electric forklift can handle a variety of goods, such as changing the bucket to handle bulk materials.
