SINOTRUK HOWO 8 x 4 Concrete Mixer Trucks Engine 371HP Concrete Mixing Equipment 10-16cbm Tank volume
8 x 4 Concrete Mixer Trucks 371HP 10cbm 8x4 with EURO2 Standard Euro2 Euro3
Quick Details
|
Place of Origin: |
Shandong China (Mainland) |
Brand Name: |
SINOTRUK |
Model Number: |
HOWO |
|
Gross Vehicle Weight: |
25000 |
driven form: |
8*4 |
fuel type: |
diesel |
|
horse power: |
266-371hp |
emission standard: |
euro2 euro3 |
condition: |
new |
|
color: |
varies |
||||
Description:
- SINOTRUCK HOWO series trucks own the elegant appearance, strong operation system and excellent safety.
- Sino Heavy Machinery Co,Ltd is the authorized company of SINOTRUK(CNHTC), and mainly deal with heavy duty trucks /all spare parts and service We supply HOWO, , KING, GOLDEN PRINCE, HOHAN series 4X2, 6X4, and 8X4 dump trucks, tractor trucks, cargo trucks, garbage trucks, oil tank trucks, water tank trucks, log trailers tractors, terminal tractors, etc. Our products arrange from 190 horse power to 410 horse power, and loading capacity cover from 5 tons to 50 tons.
Specifications:
1.The cab equips with car's configuration,1-2
sleepers,electric glass and electric rearview mirror make you very comfortable.
2.Our trucks equip with natural gas engine can save energy and reduce emission.more security system:Brakes:equip with disc brake, TPMS :tire pressure monitoring system, ASR :acceleration slip regulation,ABS (Antilock Brake System).
more comfortable factors:air bag seats, reduce car earthquake and air-condition make you more comfortable
more entertainment:with MP5 player , reduce fatigue ,amuse yourself.
Parameters of HOWO- A7 Concrete Mixing Carrier (ZZ5257GBJBM4047N1)
|
Weight Parameter
|
Complete Vehicle Kerb Mass(kg) |
14170 |
|
|
Max. Umperissiblegrossladen Weight(kg) |
25000 |
||
|
Dimension Parameter
|
External Dimensions(mm)
|
length |
10005 |
|
Wide |
2496 |
||
|
High |
3800 |
||
|
wheelbase(mm) |
4025+1350 |
||
|
Minimum Ground Clearance(mm) |
275 |
||
|
Performance Parameter |
Maximum Speed(km/h) |
78 |
|
|
Economical Speed(km/h) |
65 |
||
|
Turning diameter(m) |
18 |
||
|
Recommended
|
Engine
|
Engine Type |
D10.29-31 |
|
Rated Power (kW)/Rev(r/min) |
213 |
||
|
Max. torque (N*m)/Rev(r/min) |
1290/1200~1500 |
||
|
Gear-box |
HW20716A, HW14710 |
||
|
Clutch(mm) |
430420 |
||
|
Rear Axle |
Type |
HC1697 |
|
|
Speed Ratio |
5.73,4.8,4.42 |
||
|
Oil Box(L) |
400 |
||
|
Chassis Cross-section(mm) |
300 |
||
|
Suspension(Front, Back) |
9/12 |
||
|
Tyre |
11.00-20,11.00R20,12.00-20,12.00R20 |
||
