SINOTRUK HEAVY DUTY CARGO TRUCK , ARMY GREEN MAJESTY ZZ1167M4617C
SINOTRUK HEAVY DUTY CARGO TRUCK , ARMY GREEN MAJESTY ZZ1167M4617C
Description:
- SINOTRUCK HOWO series trucks own the elegant appearance, strong operation system and excellent safety.
- Sino Heavy Machinery Co,Ltd is the authorized company of SINOTRUK(CNHTC), and mainly deal with heavy duty trucks /all spare parts and service We supply HOWO, , KING, GOLDEN PRINCE, HOHAN series 4X2, 6X4, and 8X4 dump trucks, tractor trucks, cargo trucks, garbage trucks, oil tank trucks, water tank trucks, log trailers tractors, terminal tractors, etc. Our products arrange from 190 horse power to 410 horse power, and loading capacity cover from 5 tons to 50 tons.
| Respective vehicle Number | ZZ1167M4617C | |
|
Cab |
Model | HW70/HW76 |
|
Type |
Extended Cab, single berth, up/down and front/ back adjustable steering wheel, VOD instrumented control module, double locking safety belt, exterior sun visor. |
|
|
Engine |
Model |
WD615.95E |
|
Type |
Six cylinders inline, two valve, supercharge intercooler, supercharge postposition. |
|
|
Displacement L |
9.26 |
|
| Maximum torque (Nm) | 290 | |
|
Clutch |
430diaphragm spring clutch, Hydraulic control air assisted |
|
|
Transmission |
SINOTRUK HW series 10 gears Transmission, Transmission with main and auxiliary transmission structure, main transmission with double counter shaft, auxiliary transmission with planetary reduction. |
|
| Suspension |
Front and rear leaf spring suspension, front suspension with shock absorber, transverse stabilizer rear suspension is disconnected type with transverse stabilizer. |
|
| Steering system |
ZF8098 steering gear, ZF steering oil pump, system pressure 18Mpa |
|
|
Braking system |
Service brake: dual circuit compressed air brake. | |
|
Parking brake(emergency brake): spring energy, compressed air operating on rear wheels |
||
| Auxiliary brake: engine exhaust brake | ||
| Option: ABS | ||
| Electrical system |
Voltage: 24V generator: 1540W battery: 12V/165Ah, 2 piece |
|
| Wheelbase (mm) | 1800+5600 | |
| Front/rear suspension (m) | 1.500/1.710 | |
| Gross Mass (kg) | 50000 | |
| Curb weight(vehicle/chassis)kg | 9720 | |
| Maximum loading capacity(kg) | 40000 | |
| Complete vehicle External dimension(L*W*H) mm | 10765*2498*3290 | |
| Body volume (mm): 8600*2300*1190 | ||
We can supply different capacity and driving mode dump truck, for more in formations, kindly contact me !
Other Truck and trailer can be provide according to your request, freely contact me for the informations and quotations.
