Sinotruck 4 x 2 266HP Mobile Workshop Truck With Repair Tools Yellow With Crane Maintain Car
Sinotruck 4 x 2 266HP Mobile Workshop Truck With Repair Tools Yellow
Advantage
1.Very fast to rescue the malfunction vehicle , even the vehicle is far .
2. The work shop truck has complete fixing tools and equipment , it can repair and solve most trouble of vehicle..
3. Very excellent performance and easy to maintenance.
Quick Detail:
1. Drive Mode: 4 X 2
2. Engine Power: 266HP
3. Overall Dimension: 7540 X 2520 X3560mm
4. Wheel Base: 4600mm
Specifications
|
Complete |
Tare Weight |
11,950 Kg |
|
|
Loading Capacity |
3,050 Kg |
|
|
Drive Type |
4X2 |
|
|
Tyres |
6+ 1; 12.00R20 RADIAL TYRE, |
|
|
Max. Speed |
75 KPH |
|
|
Max. Gradeability |
40% |
|
|
Minimum Ground Clearance |
298 mm |
|
|
Overall Dimensions |
7540 x 2520 x 3560 mm |
|
|
Wheel Base |
4600 mm |
Equipments
|
Item |
Description |
Technical Data |
Measurement |
Weight |
Qty. |
|
1 |
Power Set |
Model: 40GF-4 |
2030x650x1255(mm) |
1030kg |
1 |
|
|
|
Rated Power: 40KW |
|
|
|
|
|
|
Rated Voltage: 400/230V |
|
|
|
|
|
|
Rated Frequency: 50/60Hz |
|
|
|
|
|
|
Rated Current: 72.2A |
|
|
|
|
|
|
Output: 3-phase, 4-line |
|
|
|
|
|
|
Diesel Engine: R4100ZD |
|
|
|
|
|
|
Generator Model: TZH-40 |
|
|
|
|
2 |
Welding Set |
Model: ZX7-400B |
406x530x840(mm) |
160kg |
1 |
|
|
|
Voltage: 380V |
|
|
|
|
|
|
Phase: 3 |
|
|
|
|
|
|
Frequency: 50/60Hz |
|
|
|
|
|
|
Initial Current: 29.6A |
|
|
|
|
|
|
Range: 25-250A |
|
|
|
|
|
|
Input: 19.2KVA |
|
|
|
|
|
|
Working Ambient: -10--+40oC |
|
|
|
|
3 |
Air Compressor |
Model: AW3608 |
1180x410x850(mm) |
130kg |
1 |
|
|
|
Voltage: 380V |
|
|
|
|
|
|
Frequency: 50/60Hz |
|
|
|
|
|
|
Power: 3KW |
|
|
|
|
|
|
Pressure: 0.7MPa |
|
|
|
|
|
|
Capacity: 0.36M3/mm |
|
|
|
|
4 |
Drilling Machine |
Model: RDM-1600BNT |
760x490x260(mm) |
57kg |
1 |
|
|
|
Bore Range: 3--16mm |
|
|
|
|
|
|
Power: 700W |
|
|
|
|
5 |
Vice |
Size: 150mm |
|
|
|
|
6 |
Grinding Machine |
Model: MQ3225 |
|
|
1 |
|
|
|
Size: 250mm |
|
|
|
|
|
|
Power: 700W |
|
|
|
|
7 |
Oxygen Cylinder |
Volume: 40L |
|
|
1 |
Tools
|
No |
Name |
Specification |
Quantity |
|
1 |
Bow saw frame |
|
2 |
|
2 |
Hacksaw blade |
18 tine； 32 tine |
Each 1 |
|
3 |
Manual oil gun |
|
1 |
|
4 |
Oil pot |
300cc |
1 |
|
5 |
Hand electric drill |
220V 0.6～6mm |
1 |
|
6 |
Pipe expansion ware |
|
1 set |
|
7 |
Electrical maintenance kits |
with multimeter |
1 set |
|
8 |
Screw tap |
Coarse thread M4;M5;M6;M8;M10;M12 |
6/set |
|
9 |
Screw tap |
Fine thread M8;M10;M12 |
3/set |
|
10 |
Screw tap holder |
180mm;280mm |
each 1 set |
|
11 |
Screw die |
Coarse thread M4;M5;M6;M8;M10;M12 |
6/set |
|
12 |
Screw die |
Fine thread M8;M10;M12 |
3/set |
|
13 |
Drill |
1-10mm (at intervals of)0.5mm |
2set
|
Photos
