290HP(196 Kw) 6X4 CARGO TRUCK at 2200 rpm HW15710/HW19710, 10 speed 20-40 ton
6X4 HOWO 290HP Truck Chassis Cargo Truck
Sino heavy machinery co.ltd is one of the qualified manufacturers of various
trailers, like flatbed semi-trailer, lowbed semi-trailer,cargo trailer, dump semi trailer, fuel tank
trailer, cement bulker trailer, full trailer, etc.With high standard machinery and automatic equipment,
We have built a long business relationship with many world famous enterprises such as SINOTRUCK,
SHACMAN, FAW, etc. We could provide tractor head, dump truck , concrete mixer truck, fuel tanker
truck,etc.We have exported our products to Tanzania, South Arica, Nigeria, Zambia, Malawi,
Kenya, Congo, Ghana,Algeria, the Philippines, Russia, Mongolia, Chile, Peru, Uruguay,Ecuador,etc.
|
Place of Origin: |
CHINA CNHTC |
|
Brand Name: |
SINOTRUK HOWO |
|
Model Number: |
ZZ1257M4641V/M |
|
Certification: |
ISO CCC |
| Driving type | 6x4 | ||||
| Dimension(Lx W x H)(unloaded) | 9800x2496x3048,3718 | ||||
| Wheel base (mm) | 5800+1350 | ||||
| Curb weight (kg) | 11000 | ||||
| Loading capacity (kg) | 13870 | ||||
|
Engine Styr technology, made in China |
Model (WD615.62) | SINOTRUK diesel engine,water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection | |||
| Displacement (L) | 9.726/Diesel | ||||
| Bore X stroke (mm) | 126/130 | ||||
| Max power (kw/rpm) | 195/2200 | ||||
| Max torque (Nm/rpm) | 1100/1300-1600 | ||||
| Emission | EURO II | ||||
| Fuel tanker (L) | 300 | ||||
| Clutch | Model | Single dry frictional disc,Hydraulic boosting | |||
| Gearbox | Model | HW15710, mechanism,10gears,2reverse gear, manual | |||
| Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | |||
| Assistant brake | Engine exhaust brake | ||||
| Park brake | Potential springs pressing on middle and rear wheels | ||||
| Steering system (ZF company) | Model | ZF technology, driver sit at the left hand side | |||
| Frame | Fish belly, shape, variable width, variable sections, side beam structure | ||||
| Front axle | HF 7ton technology non-driving steering axle | ||||
| Middle and Rear axle |
ST16 double reduction, hub redactor driving axle, |
||||
| Tyre | 11.00R20 | ||||
| Electrical system | Battery | 2X12V/135Ah | |||
| Generator | 28V-35A | ||||
| Starter | 5.4Kw/24V | ||||
| Cab |
Air suspension cab, sleeper, hydraulic shock absorb adjustable seat, safety belt, adjustable steering, warm air system, sunroof, sun cap, bumper |
||||
| Approaching angle/ Departure angle | 16/15 | ||||
| Overhang (front/rear) | 1500/2625 | ||||
| Max speed (km/h) | 90,102 | ||||
What we can do for customers:
1. the satisfied product with high level standard;
2. the full aspect service from order to shipping;
3. give customer most suitable advice when customer has special needs for your transportation or construction;
4. help customer to get the related spare parts of trailer or tractors if customer needs.
we are waiting for you to get this ideal products and best quotation!
