Bulk Cement Semi Trailer 50000 Liters bulk cement carrier trailer
DORIN (Ms)
1:mail : roadmachine@road-machine.com
2:Tel : 86+13210589366
3:Skype : 008613210589366
4:The company :SINO VEHICLE&EQUIPMENT COMPANY LTD
Specification:
| Weight: | ||
| Tare Weight | From 8700kg to 13000kg | |
| Tank capapcity | From 27m3 to100m3 for your choose | |
| Loading Capacity | From 30tons to 100tons | |
| Axle Weight Load | 13T/14T/16T/20T | |
| Axle: | ||
| Axle number | Two or Three | |
| Axle specs. | FUWA or BPW Brand | |
| Suspension | Common mechincal or Pneumatic Suspension | |
| Wheel | 11.00R22.5,12.00R22.5 Vacunnm tire /Triangle or Double Cone Brand | |
| King Pin | JOST 50# or 90# traction pin | |
| Dimensions | 9950/9960×2490×3950mm,12500/11000/10500×2490/2500×3950/3800mm, | |
| Support legs | 28Tons (Tongyada Brand)or JOST D200T | |
| Steel Spring | 10 pieces per axles | |
| Manhole | 2/3/4 pieces(Diameter is 500mm) | |
| silo | single silo/double silos/three silos | |
| Air compressure | 10m3 /12 m3 /14m3 | |
| Diesel Engine | Weichai 495/4100/4105 | |
| Electric Engine | Can be choose freely accroding to customer requirement. | |
| Tire: | ||
| Number of Tire | can be choose freely | |
| Spare Tire Carriers | 2 pieces | |
| Frame: (specs. and materials) | ||
| The material of | The tanker body made of 5/6mm steel plate, | |
| Tanker body | the forside head and back side head made of 5/6mm steel plate,the shape can be column. | |
| Brake: | ||
| Brake | Kemi Brand of China | |
| Brake Chamber | Four double and two single chamber( TKL brand ) | |
Description:
SINOMTP are engaged in offering a quality range of bulk cement carrier trailer. The bulk cement
carrier we offer is widely demanded for their durability and reliability. Safe to use and easy to install
these products are valiable in various size and spefications.
Applications:
Bulk Cement Semi Trailer Suitable for fly ash, cement, lime powder, mineral powder, granular base, such
as a particle diameter of not more than 0.1mm powder dry bulk transport materials.
Competitive Advantage
1 Flat butt automatic welding machine(splice plate machine), to ensure the steel is flat, and seam is welded
by one side in shape by two sides. So there is no minimal deformation, also clean and beautiful seam on
both sides, round and smooth transfers.
2Automatic girth welding machine for irregular shape tank. The welding seams is good in appearance, high
in welding quality and production efficiency.
3Tube bending machine, the tube of tanker body adopt one time forming bending tube, improve the pipeline
of safety and good appearance.
4 Professional paint workshop for tanker trailer, from sand blasting, prime to top painting, guarantee the
tanker body of brightness and the adhesion of paint.
