4x2 New Condition Light Duty Commercial Trucks / Howo Dump Truck CDW 5-10T
Price:
Negotiable
MOQ:
1
Delivery Time:
Within 35 days
Brand:
CIVL
Product Description
4x2 New Condition Light Duty Commercial Trucks / Howo Dump Truck CDW 5-10T
Product Description
| CDW 757B3P SERIES | |
| Model | CDW3110A2C3 |
| Cab and Panel | 2080 cab,Double torsion bar |
|
|
Type: YC4E160-33 |
| Type:4 cylinder, direct injection, water cooling,4 stroke,Euro III | |
| Max horse power: 160hp | |
| Rated revolution: 2600 rpm | |
| Max. Torque: 520 N.m at 1300~1700 r/min | |
| Displacement: 4.257 L | |
| Cylinder bore×route: 110×112 mm | |
|
|
Type: HW90710,Manual with synchro, 10 forward and 2 reverse |
|
Ratio: 11.987,8.973,6.748,4.644,3.805,2.581,1.932,1.453,1,0.819, |
|
|
|
Front type: 145D1A,driven front axle |
| Rear axle type: 153N1,Pipa Style,casting axle,with differential | |
| Rear axle ratio: 6.5 | |
|
|
Frame: 280/10,ladder shaped frame,280mm height,800mmwideth,10mm thickness |
| Front overhang: 1061-Ⅱ++,11pcs,telescopic shock absorber | |
| Rear overhang: 153+,11pcs main spring and 8pcs assistance spring | |
| Fuel tank:Iron steel,Volume 150L | |
|
|
Type:Steering wheel |
| Steering diameter:450mm | |
| Max. cycles:5.5 | |
|
|
Motor brake:Double Circuit air brake |
| Parking brake: Brake | |
| Auxiliary brake: Exhausted Brake | |
| Tyre | Tyre:9.00-20×7 |
| Electronic | Voltage: 24V,cathode ground connection |
|
|
Wheelbase: 3650 mm |
| Wheeltrack: 1750 mm/ 1725mm | |
| Overhang: 1260 mm / 1490 mm | |
| Approaching angle/Departure angle: 24 / 23 | |
| Inner dimension: 4140mm×2200mm×800mm | |
| Total dimention: 6395 ×2300×2630mm | |
| Lifting | Single cylinder 180mm×660mm |
|
|
Rated mass:4800Kg |
| Load capacity:10000 kg | |
| Total mass:14800 kg | |
| Front axle load capacity:4590 kg | |
| Rear axle load capacity:6905 kg | |
Delivery Detail: Shipped in 30 days after payment
