Sinotruk 6x4 Euro2 10 Tire Heavy Cargo Trucks , 30 - 40 Ton Transport Vehicle
Price:
Negotiable
MOQ:
1
Delivery Time:
Within 35 days
Brand:
CIVL
Product Description
sinotruk 6x4 Euro2 10tire 30-40ton cargo truck transport vehicle
Product Description
| Truck Brand | SINOTRUK—HOWO ( LHD or RHD) | ||||
| Truck Model | ZZ1317N3867 | ||||
| Dimension(Lx W x H)(unloaded)(mm) | 11182x2496x3700 | ||||
| Cargo body dimension (L x W x H)mm | 8600x2400x2200mm | ||||
| Approaching angle/Departure angle(°) | 16/14 | ||||
| Overhang(front/rear) (mm) | 1500/2732 | ||||
| Wheel base (mm) | 1950+4600+1400 | ||||
| Max speed(km/h) | 101 | ||||
| Curb weight(kg) | 11280 | ||||
| Loading Weight(kg) | 40000 | ||||
|
Engine ( technology, made in China) |
Model | water-cooled,four strokes,6 cylinders in line with water cooling , directly injection | |||
| Fuel type | Diesel | ||||
| Horse Power, max(kw/rpm) | 371HP | ||||
| Emission | EURO II | ||||
| Fuel tanker capacity(L) | 300 | ||||
| Transmission | Model | HW19710,10 forwards and 2 reverse | |||
| Brake system | Service brake | Dual circuit compressed air brake | |||
| Parking brake | spring energy, compressed air operating on rear wheels | ||||
| Auxiliary brake | Engine exhaust brake | ||||
| Steering system | Model | hydraulic steering with power assistance | |||
| Front axle | HF7 | ||||
| Rear axle | HW1279 | ||||
| Color | Optional | ||||
| Tyre | 295/80R22.5 tubeless tires | ||||
| Tyre quantity | 12pcs + 1 spare | ||||
| Electrical system | Battery | 2X12V/165Ah | |||
| Alternator | 28V-1500kw | ||||
| Starter | 7.5Kw/24V | ||||
| Cab | HW76 cab, one sleeper with air conditioner, all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers | ||||
Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
