3 Axles CIVL Brand 42,000 Liter Fuel Tanker Semi Trailer With 4 Inch Manhole Cover
3 Axles SHMC Brand 42,000 Liter Fuel Tank Semi Trailer With 4 Inch Manhole Cover
Description:
3 Axles 45000 50000 liters Steel Aluminum Best Price Oil Diesel Fuel Tanker Tank Semi Trailer,
According to clients' requirements, we can customize different volume and compartment.
The popular oil tanker trailer models include: 3 Axles 60,000L fuel tanker trailer / 3 Axles 45,000L fuel tanker trailer / 3 Axles 50CBM fuel tanker trailer / 42CBM fuel tanker trailer / 40CBM fuel tanker trailer.
According to the Material, we have Carbon Steel / Stainless Steel / Aluminum Alloydiesel oil fuel tanker tank semi trailer.
So customers can choose what tanker they like.
Specification:
| Trailer Model | 3 Axles 45000 50000 liters Steel Aluminum Best Price Oil Diesel Fuel Tanker Tank Semi Trailer |
| Overall Dimension | 11900x2500x3800(Lx W x H)(mm) |
| Function | transport Fuel, Oil, Diesel |
| Thickness(mm) |
Tank body: Q235/5mm carbon steel End plate: Q235/6mm carbon steel |
| Volume | 30000L-60000L |
| Axle Brand | FUWA 13Ton Axle, top brand |
| Axle Number | Three |
| Compartment | 3-9compartments |
| Manhole cover | 500mm manhole cover. 3 sets with3 breath valve. |
| Ladder | Top ladder with handrail, side ladder |
| Discharge valve | 4''disc valve |
| Discharge pipe | 4''seamless steel tube |
| Suspension system | Leaf spring suspension |
| Bottom valve quantity | 3 units |
| Steel Spring |
10/10/10 leaf spring suspension 90mm width, 13mm thickness |
| The material of Main beam | The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm,middle plate is 8mm. |
| Tire Type and quantity | 12R22.5 Taitong top brand 12units |
| Traction Pin | 50mm/90mm, jost brand |
| Spare Wheel Bracket | 2 pieces |
| Tool Box | 1 Standard |
| Landing Gear | Standard brand 28ton external, 2 speed, zhenhua brand |
| Brake system | Dual Line braking system |
| Brake air chamber | Six big double air chambers |
| Electrical system | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
| Tail lamp with turn signal, brake light & reflector, side lamp etc. | |
| One set 6-core standard Cable. | |
| Side Guard | According to customer’s requirement |
| Painting | According customer requirement |
| Packing | Polish with wax before shipping |
Detailed photo:
With over 51 years of experience , we have becoem one of the key manufacturers of trucks and road machiens in China .
Exporting to more than 50 countries for 14 years .
Package&Shipping:
Company Introduction:
SINO HEAVY MACHINERY CO.,LTD. Is a professional supplier of various SINOTRUK brand trucks with more than 30 years manufacturing and exporting experience.
We mainly focus on various trucks' R&D,Producing and sales kinds of trucks with different function,such as heavy duty/medium duty/light duty truck,mining tipper,tractor truck,various construction project equipment etc...
Our all products with world-known brands spare parts,such as ZF steering and oil pump;WABCO braking system;VOSS braking connectors made in Germany;MANN+HUMMEL fuel filer system and air filter;VOD instrument and electric control block;German BEHR cooling system etc...Those high quality parts supplying ensure our products the first-class quality level and excellent driving performance.
Till now we have exported more than 30 countries and areas including Asia,Southeast Asia,Africa,South Africa etc..
We are committed to help more countries customer's engineering construction, make the world more harmonious and beautiful!
Quality Inspection:
Service:
Pre-service:
- Inquiry and Consulting support.
- Sample testing support.
- View our factory.
- Design various solutions as buyer's requirement.
After-sale service:
- Training how to use and maintain the truck.
- Our engineers supply the support of technology.
- 12 months warranty for 3 key spare parts(Engine,Transmission,Axle)
- Parts supply on time.
- 24 hours service and technology support.
