Northbenz Beiben 6x4 6x6 10 Wheel Cargo Lorry Truck Heavy Duty 25 Ton / 30 Ton
Northbenz Beiben 6x4 6x6 10 wheel Heavy Duty 25ton 30ton 35ton Cargo Lorry Truck
| Products Technical Specification | ||
| Product Name | Beiben 6*6 Truck | |
| Chassis Model | ND22500F44J | |
| Fuel type | Diesel | |
| Cabin | Beiben half row | |
| Whole vehicle main dimensions (mm) | Overall dimensions (L×W×H) | 9526*2500*3340 |
| Cargo body dimensions | 6280*2300*800 | |
| Wheel base | 4450+1450 | |
| Front overhang | 1410 | |
| Rear overhang | 2055 | |
| Min. ground clearance | 500 | |
| Weight data (kg) | G.V.W | 25000 |
| Curb weight (chassis) | 12250 | |
| Max payload | 20000 - 30000 | |
| Whole vehicle main performance |
Max. speed (km/h) | 90 |
| Max. slope of climb (%) | 30 | |
| Engine | Model | WP10.300E40 |
| Maximum power | 221kw / 300hp | |
| Number of cylinders | 6 | |
| Displacement (L) | 9.726 | |
| Engine Manufacturer | Weichai Power Co., Ltd. | |
| Gear box | Number of gears | FAST,9 forward gears & 1 reverse |
| Axle | Front Load capacity (ton) | 6.5 |
| Rear Load capacity (ton) | 13 | |
| Suspension | Front/Rear-Leaf spring | 10/13 |
| Steering Wheel | left/right hand drive | RHD |
| Brake system | Service brake | Air braking |
| Electric device | Rated voltage | 24V |
| Tyres & Quantity |
12.00-20 & 10+1
|
|
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
