Sinotruk 70 tons Capacity Gray Color Construction Tipper Truck 371 Hp Mining Dump Truck With Half Cabin
Tipper Truck Mining Heavy Duty Dump Truck 50 Tons 371 Hp Mining Dump Truck
Product specification :
| Pay loading | 70tons |
| Brand | Sinotruk HOWO |
| Cabin | Half cabin |
| Model No | ZZ5707S3840AJ | |||
| Cab | HOWO7D Air conditioner | |||
| Engine | Model | WD615.47 | ||
| Power(PS/RPM) | EUROII 273/2200 | |||
| Displacement(L) | 9.726 | |||
| Transmission | HW19710 | |||
| Front axle | HF12 Max.loading:12000kg | |||
| Rear axle | AC26 Max.loading:26000 kg | |||
| Steering gear | ZF8098 | |||
| Electric system | Voltage | 24V, negative grounded | ||
| Batteries | 2*12V/135Ah | |||
| Starter power | 24V/5.4KW | |||
| Wheels and Tyres | 14.00-25 | |||
| Fuel tank (L) | 300 | |||
| Carriage Internal Dimensions(mm) | Steel thickness of Carriage |
Floor:12 Side:8 |
||
| Cargo Dimensions | 4300*2300*1600 | |||
| Weight(Kg) | Gross Vehicle Weight | 100000 | ||
| Cerb Weight | 29000 | |||
| Vehicle Dimensions (mm) | Overall L*W*H | 8700*3300*4340 | ||
| Wheelbase(mm) | 3625+1350 | |||
| Performance | Maximum speed(km/h) | 63Km/h | ||
Main Parameters: We offer various of type dump trucks to meet your needs.
| Product model | Power(Ps) | Drive mode | Total weight(kg) | Wheel base(mm) | Van Length(mm) |
| ZZ570* | 371~420 | 6*4 | 70000 | 3600~4800 | 5500~7500/3100 |
| ZZ550* | 371~420 | 6*4 | 50000 | 3600~4800 | 5500~7500/2800 |
| ZZ530* | 320~380 | 6*4 | 25000 | 3200~4300 | 5400~6300/2300 |
| Vehicle series: 30,50,70 | |||||
Competitive Advantage:
1) competive price, cost-effective
2) reliable quality
3) good after slaes service, which can send engineers for traning and maintainance
4) all kinds of cargo body structure can be designed and produced according to your request,
make it have light curb weight , high rigidity , high loading capacity
5) The optimized hydraulic control system helps to avoid wrong operation, it has higher
safety and running efficiency.
6) low fuel consumption
7) strong enough engine
8) with all kinds of truck model, which can fulfil your requirements
9) using the high strength steel, make it has a long service life
10) fast delivery time, we can arange production according to your needs exactly and quickly
11) professional import and export dealing precedure, make customs clearance more high efficiency
12) excellant apperance of cabin, safety, reliable
13) quick and efficient spare parts supply bring you more convenient
14) you can choose cargo body with Front lifting type or Middle lifting type which you prefered
15) The hydraulic sytem using HYVA brand or Domestic famouse brand
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
