Electric Piston Mini Air Pump 15L/m Air Flowrate 30kPA Air Pressure
Electric Piston Mini Air Pump 15L/m Air Flowrate 30kPA Air Pressure
It is Piston mini air pump, it has low noise and high air press 30kpa and high air flowrate output 15L/m,
the most important is long lifetime, more than 10,000hours.
Quick Detail:
1.Place of Origin:Zhejiang China (Mainland)
2.Brand Name:Cinh or Blank
3.Structure:Diaphragm Air Pump
4.Usage:Air Pump
5.Flowrate:15L/m
6.Fuel:Electric
7.Pressure:30KPA
Specifications:
| ITEM | SPECIFICATION |
| Air Output: | 30SCFH(15Lpm) |
| Pump Pressure: | 4.5PSI(30kpa) |
| Power Requirement: | AC220V,AC120V, AC24V or AC12V, 50Hz or 60Hz |
| Power Consumption: | 10W |
| Pump Design: | Double diaphragm, duckbill valves |
| Pump Body: | Aluminium |
| Outlet & Inlet Dia: | 0.3"(7.6mm) |
| Electrical Connections: | 1-ft(300mm)Insulated wire pair |
| Noise Level: | 40db unconnected, connected operation will reduce db level |
| Dimension(LxWxH): | 4.2"x3"x2.9"(106x76x74mm) |
| Net Weight: | 0.62kgs |
Applications:
intermittend pneumatic compression(medical)
compression therapy
ozone generator
aquarium
recovery system
fragrance diffuser
air bed
Atmospheric Detection
Dosing chemical material
air cloth
medical applications
industrial applications
balloon
medical
humidifier
blood pressure
gas monitor
dosing
cooling system
ink
Performance Curve
