IP67 Waterproof LED Power Supply – 18‑30V DC 0.7A Constant Current LED Driver for Outdoor Lighting
Price:
negotiate
MOQ:
10
Delivery Time:
7-10 working days
Brand:
MEAN WELL
Product Description
IP67 Waterproof LED Power Supply – 18‑30V DC 0.7A Constant Current LED Driver for Outdoor Lighting
Product Overview
The MeanWell XLG series Constant Current LED Power Supply delivers reliable, stable performance for LED lighting systems. Designed with an operating temperature range of -40°C to +80°C, this waterproof IP67-rated driver is ideal for demanding outdoor and industrial environments such as street lights, landscape lights, garden lights, floodlights, tunnel lights.
Key Features
- The driver provides stable constant current (0.7A), ensuring flicker‑free lighting and extended LED lifespan — ideal for premium LED fixtures.
- Its IP67 waterproof rating protects against dust and water immersion, making it ideal for outdoor and harsh environment installations.
- Supports 100‑277V AC wide input voltage, matching global power systems without extra converters.
- Built with an aluminum housing for superior heat dissipation and mechanical protection.
- Operates reliably from ‑40°C to +80°C, suitable for extreme weather conditions.
Performance Benefits
Stable & Reliable Operation
Ensures flicker-free, consistent brightness for high-end LED lighting applications requiring precise illumination control.
Energy Efficient
High efficiency design reduces electricity consumption and operating costs while supporting environmental sustainability.
Durable Construction
Robust aluminum housing withstands heat, humidity, and vibrations for extended service life and reduced maintenance.
Versatile Applications
Compatible with various LED lighting products for both residential and commercial lighting installations.
Technical Specifications
| Parameter | Specifications |
|---|---|
| Product Name | IP67 Waterproof LED Power Supply – 18‑30V DC 0.7A Constant Current LED Driver for Outdoor Lighting |
| Power Rating | 21W |
| Output Current | 0.7A |
| DC Voltage | 18-30V |
| Input AC Current | 0.3A/100-277V |
| Efficiency | ≥88% |
| Waterproof Level | IP67 |
| Operating Temperature | -40°C to +80°C |
| Material | Aluminum Housing |
| Package Weight | 0.34kg/pcs |
| MODEL | XLG-20-L-□ | XLG-20-M-□ | XLG-20-H-□ | |
| OUTPUT | RATED CURRENT (Default) | 350mA | 500mA | 700mA |
| CONSTANT CURRENT REGION | 32.4~54V | 25.2~42V | 18~30V | |
| RATED POWER | 18.9W | 21W | 21W | |
| OPEN CIRCUIT VOLTAGE (max.) | 60V | 50V | 40V | |
| CURRENT TOLERANCE | ±8.0% | |||
| OUTPUT CURRENT RIPPLE | <20% | |||
| SETUP, RISE TIME | 500ms/150ms @115VAC, 230VAC | |||
| LINE REGULATION | <±3% | |||
| INPUT | VOLTAGE RANGE | 90~305VAC (Please refer to "STATIC CHARACTERISTIC" section) | ||
| FREQUENCY RANGE | 47~63Hz | |||
| POWER FACTOR | PF≧0.97/115VAC, PF≧0.95/230VAC, PF≧0.91/277VAC@full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section) | |||
| TOTAL HARMONIC DISTORTION | THD< 20%(@load≧50%/115VC,230VAC; @load≧75%/277VAC) (Please refer to “TOTAL HARMONIC DISTORTION(THD)” section) | |||
| EFFICIENCY (Typ.) | 89% | 88.50% | 88% | |
| AC CURRENT | 0.3A/115VAC 0.2A/230VAC 0.2A/277VAC | |||
| INRUSH CURRENT (Typ.) | COLD START 5A(twidth=350μs measured at 50% Ipeak) at 230VAC; Per NEMA 410 | |||
| MAX. No. of PSUs on 16A CIRCUIT BREAKER | 42 units (circuit breaker of type B) / 42 units (circuit breaker of type C) at 230VAC | |||
| LEAKAGE CURRENT | <0.75mA/277VAC | |||
| NO LOAD POWER CONSUMPTION | No load power consumption <0.5W | |||
Applications
- LED Street Lighting
- Landscape Lighting
- Garden & Patio Lights
- Outdoor Floodlights
- Industrial Outdoor Lighting
Shipping & Delivery Informations
| Service | Delivery Time |
|---|---|
| DHL/UPS/TNT/FEDEX | 4-5 working days |
| EMS | 10-15 working days |
| HK Post Air Mail Register | 15-18 working days |
| Standard Delivery Time | 3-4 working days |
| Trade Terms | FOB | EXW | CIF | CNF |
| Sample Availability | YES |
