60W 24V Constant Voltage LED Power Supply DIN Rail Mountable for Household and Industrial Lighting
Price:
Negotiate
MOQ:
10
Delivery Time:
7-10 working days
Brand:
MEAN WELL
Product Description
60W 24V Constant Voltage LED Power Supply DIN Rail Mountable for Household and Industrial Lighting
Suitable for household and industrial LED lighting applications with reliable performance and safety certifications.
Key Features
- Ultra slim design with 52.5mm (3Su) width
- Universal input 85-264VAC (277VAC operational)
- No load power consumption <0.3W
- Isolation class II
- Passes LPS (Limited Power Source) requirements
- DC output voltage adjustable
- Protections: Short circuit / overload / over voltage
- Cooling by free air convection (working temperature: -30°C to +70°C)
- DIN rail TS-35/7.5 or 15 mountable
- LED indicator for power on
Product Description
The HDR-60-24 is an economical ultra slim 60W DIN rail power supply, designed for installation on TS-35/7.5 or TS-35/15 mounting rails. With a compact 52.5mm (3Su) width, it saves valuable space inside electrical cabinets.Featuring a plastic housing for effective protection against electric hazards, this power supply achieves up to 90% working efficiency. The entire series operates reliably in ambient temperatures ranging from -30°C to 70°C under natural air convection. Comprehensive protection functions and relevant certifications for home automation and industrial control apparatus (IEC62368-1, UL508, UL62368-1, BS EN/EN61558-2-16) make the HDR-60 a highly competitive power solution for both household and industrial applications.
Technical Specifications
| Product Name | 60W 24V Constant Voltage LED Power Supply DIN Rail Mountable for Household and Industrial Lighting |
| Model No. | HDR-60-24 |
| Power | 60W |
| Input Voltage | 85-264VAC |
| Input Efficiency | 90% |
| Output Voltage | 24V |
| Output Current | 2.5A |
| Warranty | 3 years |
| Dimension | 90x54.5x52.5mm |
| Packing | 0.074kg, 160pcs/12.9kg/1.09CUFT |
| MODEL | HDR-60-5 | HDR-60-12 | HDR-60-15 | HDR-60-24 | HDR-60-48 | |
| OUTPUT | DC VOLTAGE | 5V | 12V | 15V | 24V | 48V |
| RATED CURRENT | 6.5A | 4.5A | 4A | 2.5A | 1.25A | |
| CURRENT RANGE | 0~6.5A | 0~4.5A | 0~4A | 0~2.5A | 0~1.25A | |
| RATED POWER | 32.5W | 54W | 60W | 60W | 60W | |
| RIPPLE & NOISE (max.) Note.2 | 80mVp-p | 120mVp-p | 120mVp-p | 150mVp-p | 240mVp-p | |
| VOLTAGE ADJ. RANGE | 5.0~5.5V | 10.8~13.8V | 13.5~18V | 21.6~29V | 43.2~55.2V | |
| VOLTAGE TOLERANCE Note.3 | ±2.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | |
| LINE REGULATION | ±1.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | |
| LOAD REGULATION | ±1.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | |
| SETUP, RISE TIME | 500ms, 50ms/230VAC 500ms, 50ms/115VAC at full load | |||||
| HOLD UP TIME (Typ.) | 30ms/230VAC 12ms/115VAC at full load | |||||
| INPUT | VOLTAGE RANGE | 85~264VAC (277VAC operational) 120~370VDC (390VDC operational) | ||||
| FREQUENCY RANGE | 47~63Hz | |||||
| EFFICIENCY (Typ.) | 85% | 88% | 89% | 90% | 91% | |
| AC CURRENT (Typ.) | 1.2A/115VAC 0.8A/230VAC | |||||
| INRUSH CURRENT (Typ.) | COLD START 30A/115VAC 60A/230VAC | |||||
Product Image
Shipping&Delivery Informations
| DHL/UPS/TNT/FEDEX | 4-5 working days |
| EMS | 10-15 working days |
| HK Post Air Mail Register | 15-18 working days |
| Trade Terms | FOB | EXW | CIF | CNF |
| Sample Availability | YES |
| Standard Delivery Time | 3-4 working days |
Applications
- Street lighting systems
- Highway LED lamps
- Tunnel lighting
- Square and area lighting
- Road and parking spot lamps
- Track lighting fixtures
- Landscape and scenery area lighting
- Retail and commercial lighting
- High luminous flux applications
For any requests or questions, please feel free to contact us.
