1-10V /Dali Dimming UFO Highbay Light 150W 200W 240W 300W IP66 150lm/W
- IP66 High bay light
- Input: AC 100-277V, 50/60Hz
- Luminous Flux: 150±5% LM/W
- CRI: >80Ra
- PF: >90%
- Lifespan: ≧50000Hrs
- IP rate: IP66
- Dimming: 0-10V
- PowerSupply: MEANWELL /SOSEN / ZH
| Mode No. | MF-UFO-H10Dw | MF-UFO-H150w | MF-UFO-H200w | MF-UFO-H240W |
| Input Votage | AC100-277V 50/60Hz | AC100-277V 50/60Hz | AC100-277V 50/60Hz | AC100-277V 50/60Hz |
| Rated Power | 100W | 150W | 200W | 240W |
| LED | 210PCS*2835 | 300PCS*2835 | 375PCS*2835 | 430PCS*2835 |
| PF | >0.95 | >0.95 | >0.95 | >0.95 |
| LED Brand | Lumiled | Lumiled | Lumiled | Lumiled |
| Luminous Flux | 15000lm±5% | 22500lm±5% | 30000lm±5% | 36000lm±5% |
| CRI | Ra>70,80,90 | Ra>70,80,90 | Ra>70,80,90 | Ra>70,80,90 |
| cc | 3000-6500K | 3000-6500K | 3000-6500K | 3000-6500K |
| Beam Ange | 60/90/120 | 60/90/120 | 60/90/120 | 60/90/120 |
| Driver Brand | MW/SOSEN/ZH | MW/SOSEN/ZH | MW/SOSEN/ZH | MW/SOSEN/ZH |
| THD | <10% | <10% | <10% | <10% |
| lKRating | IKo8 | IKO8 | IK08 | lKO8 |
| lP Rating | IP66 | IP66 | IP66 | IP66 |
| life Span | 50000Hrs | 50000Hrs | 50000Hrs | 50000Hrs |
| Size | 270"149mm | 300*158mm | 330*164mm | 330*164mm |
| N.w | 2.50kg | 2.80kg | 4.00kg | 4.10kg |
| Gw | 2.90kg | 3.40kg | 4.65kg | 4.75kg |
| Certification | ETL/DLC/CE/SAA/FCC/RoHS/CCC | |||
*Lightweight, impact resistant fixture is designed for easy and safe installation.
*Die-casting technology by ADC12, excellent thermal management, reduce the temperature difference and ensure the lumen depreciation
*Multiple mounting options for a variety of applications, Pendant, loop.
*High strength polycarbonate lens, achieve IK 08, Anti-UV, transmittance > 94%
*Multiple lighting distributions: 60°/90°/120°
*Top brand LED chip and driver, ensure the product quality and lifetime
*Ingress Protection Rating: IP66
*Operation Temperature: -35 C -+50
*Up to 140lm/W: 170lm/W:190lm/W
*3000K.4000K.5000K.5700K color temperature
*CRI>80
*Offered in 100,150, 200 and 240W
Multiple lighting distributions: 60°/90°/120°
100W 150W
200W 240W
Warehouses and Storage Facilities/Manufacturing Plants/Gymnasiums and Sports Facilities/Retail Stores/Parking Garages and Outdoor Areas/Exhibition Halls and Event Spaces...
