20W/2X20W/3X20W/4X20W Square Trim Aluminum Housing Recessed Downlight Interior Lighting LED Ceiling Down Light
Factory Price 7W 12W 20W Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas
- Can directly replace compact fluorescent lamp downlights
- Provides energy savings of up to 60% compared to CFL lamp-based luminaires
- Offers a uniform and homogenous light output
- Features a functional and aesthetically pleasing design
- Easy installation with fast connection options
- Comes with a 3-year guarantee for added peace of mind
Anti Glare
Reflective cup
Aluminum structure with strong heat dissipation
Beam angle:
Product pictures:


Parameters
Electrical Data:
| Nominal Wattage |
7W / 12W / 20W x1 x2 x3 x 4
|
| Nominal Voltage | 100-240V |
| Mains Frequency | 50-60Hz |
| Nominal Current | 350,000mA |
| Power Factor λ | 0.9 |
| Protection Class | II |
| Operating Mode | Electronic Control Gear (ECG) |
Application & Mounting:
| Ambient Temperature Range | -20 °C~ 40°C |
| Type of Connection | Terminal, 2-pin |
| Type of Protection | IP40 |
| Dimmable | No |
| Mounting Type | Recessed |
| Mounting Location | Ceiling |
| Application Environment | Indoor |
| LED module Replaceable | Not replaceable |
| Lifespan L70/B50 at 25 °C | 30000 h1) |
| Number of Switching Cycles | 15000 |
Material & Color:
| Product Color | White |
| Housing Color | Grey |
| Body Material | Aluminum |
| Mercury Content | 0.0mg |
| Diameter |
Refer to below table
|
| Length |
Refer to below table
|
| Height |
Refer to below table
|
| Product Weight | 610.00g |
| Code | Item Size(LxHxM) | Cutting Size |
| MF-TH201-S7W | 62x62x85mm | 55x55mm |
| MF-TH201-S2X7W | 115x62x85mm | 110x55mm |
| MF-TH201-S3X7W | 170x62x85mm | 160x55mm |
| MF-TH201-S4X7W | 115x115x85mm | 110x110mm |
| MF-TH201-BS12W | 85x85x98mm | 75x75mm |
| MF-TH201-BS2X12W | 159x85x98mm | 150x75mm |
| MF-TH201-BS3X12W | 232x85x98mm | 220x75mm |
| MF-TH201-BS4X12W | 158x158x98m | 150x150mm |
| MF-TH201-CS20W | 103x103x130mm | 95x95mm |
| MF-TH201-CS2X20W | 197x103x130mm | 190x95mm |
| MF-TH201-CS3X20W | 291x103x130mm | 287x95mm |
| MF-TH201-CS4X20W | 192x192x130mm | 187x187mm |
| Luminous Flux |
7W 700lm / 12W 1200lm/ 20W 2000lm x1x2x3x4
|
| Luminous Efficacy | 100 lm/W |
| Color Temperature | 3000K 4000K 6000K |
| Light Color (designation) | Warm White |
| CRI | ≥80 |
| Beam Angle |
8°/15°/24°/36°/60°
|
LED downlights are widely utilized in a variety of indoor settings, including residential, commercial, public, and industrial spaces. They offer efficient and reliable lighting solutions for a range of environments such as living areas, bedrooms, kitchens, offices, retail stores, restaurants, hotels, schools, libraries, hospitals, warehouses, and factories. LED downlights are favored for their energy efficiency, extended lifespan, and adaptability. They can be tailored to deliver various light colors, brightness levels, and beam angles, ensuring they meet diverse lighting requirements.



We are a factory specializing in the production of LED lights for a wide range of indoor and outdoor applications. Our product portfolio includes LED downlights, LED panel lights, LED wall lights, LED tube lights, LED spotlights, LED track lights, LED ceiling lights, LED high bay lights, LED tri-proof lights, LED flood lights, LED high mast lights, LED stadium lights, LED street lights, LED garden lights, and LED explosion-proof lights. These products are widely installed in various large-scale lighting applications, such as farms, factories, schools, bridges, tunnels, ports, subways, airports, mines, hospitals, and more.
With a focus on LED lighting, we have gained expertise in producing and exporting high-quality LED light fixtures to over 132 countries in Asia, Europe, North America, Latin America, and the Pacific Ocean islands. Our LED lights are manufactured under the ISO9001 system, and our professional team ensures efficient management throughout the production process. We hold certifications such as CE, CB, ENEC, RoHS, CSA, UL, SAA, and REACH, which are accredited by reputable organizations like SGS or TUV, depending on the LED light family.
At MF, our dedicated R&D team is driven by passion, persistence, and technological expertise. Our engineers meticulously develop our LED lights, paying attention to even the smallest details. Our goal is to provide high-quality LED lighting solutions by combining our visionary approach with in-depth knowledge. We firmly believe in the power of lighting to enhance the quality of life and work for users worldwide. As a team, we understand that "LIGHTS THE WORLD" is not just a slogan but a commitment that we strive to fulfill through our hard work, day by day.
