3000 Watt 40000LM Outdoor Led Stadium Flood Light With CREE LED / Meanwell Driver
3000 watt at 40000LM outdoor IP67 led stadium flood light with CREE LED, Meanwell driver
Description:
Ming Feng Lighting Co.,Ltd IP67 High power led flood light use USA CREE LED, Customized higher
efficiency 130-150lm/w are available.Biggest cooling area. Japan calculusoptical lens improve the utilization of led fllood light chips effictively. Unit-design approach improve the luminous area of led floodlight greatly.
Flexible installation, save more your cost CE,RoHS,TUV,CB,FCC,DLC,GS,SAA certificated 8 years free warranty. High CRI up to 80-90. Light efficiency up to 150lm/w---our led floodlight. We have already produced the 80w to 4000w. Widely used in stadiums, football field, basketball court, golf and tennis court, racetrack, badminton, roads, high-rise buildings, light towers, parking lot, tunnels, high mast lighting and etc.
Specifications:
|
Item |
MF-FL-3000W |
|
Input voltage |
90-305Vac 50Hz/60Hz |
|
LED Power |
3000W |
|
System Consumption |
3000±100W |
|
Delivered Flux |
403000-465000lm |
|
IP Rating |
IP67 |
|
Beam Angle |
10°, 24°, 38°, 60°, 90° , 120° |
|
Color temperature |
3000K / 4000K / 5000K / 6500K |
|
LED Chip |
CREE |
|
LED Driver |
Meanwell |
|
Color Rendering Index |
Ra>80 |
|
Power Factor |
≧0.98 |
| Color of Housing | Silver / Gery / Black |
|
Lifespan |
100,000hrs |
|
Operation Environment |
Temperature:-40°C~65°C/Humidity:10%~90% |
| Storge Temperature | -40°C~50°C(Best 25°C) |
|
Material |
Anti-corrosion Die Cast Aluminum Alloy |
|
Product Size(mm) |
1140*934*104mm |
|
Net Weight |
98.0Kg |
|
Certificate |
CE/RoHS/TUV/GS/SAA/FCC/DLC/ETL |
|
Warranty Period |
8 years |
Competitive Advantage:
1. Japan secondary optical DIWL lens, light transmittance of PMMA up to 98%. 10°24°38°60°90° beam angles are available.
2. High strength structure with 6063-T5 aluminum alloy. Coated with corrosion resistant polyester powder, real anti-corrosion.
3. Multi-angle 10°, 24°, 38°, 60°, 90° , 120° for optional.
4. Intelligent dimming system, 0-10V, 1-10V, Dali, DMX512 dimming models are available
5. Applications: Ming feng LED Flood Light widely used in stadiums, football field, basketball court, golf and tennis court, racetrack, badminton, roads, high-rise buildings, light towers, parking lot, tunnels, high mast lighting and etc.
6.Customized USA Packaged CREE LED, 130-150lm/w, CRI up to Ra80-95. Junction temperature <70°C. More stable than other LEDs.
7.TaiWan MeanWell LED Drivers, wide AC90V~305V, PF>0.98, low THD<9%.
8. Design lifespan 100,000hrs.
