Transmission Line Tool Anti Twist Steel Wire Rope Nominal Dia. 13mm
Price:
Negotiable
MOQ:
1000meters
Delivery Time:
15~25 days
Brand:
BOYU
Product Description
Transmission Line Tool Anti Twist Wire Rope Nominal Dia. 13mm
| TYFUX Anti-Twisting Steel Braided Rope | ||||||
| Anti-twisting braided wire rope with high strength hot dip galvanized steel quality air processed by the special process of special woven rope line. | ||||||
| It has high strength, good flexibility, corrosion rust-proof, not to fight the golden hook, and difficult to tie, long life and so on. | ||||||
| Tension applied to pay-off power lines construction, lifting equipment with the balance shaft and the tail rope of mine, port and other major lift crane wire rope does not rotate when the required place. | ||||||
| Performance Item no. | YL9-12x19 | YL11-12x19 | YL13-12x19 | YL15-12X19 | YL18-12X19 | YL20-18X19 |
| Nominal Dia.(mm) | 9 | 11 | 13 | 15 | 18 | 20 |
| Structure | 12 Strands | 12 Strands | 12 Strands | 12 Strands | 12 Strands | 18 Strands |
| Breakage Tension(kN) | 55 | 80 | 120 | 158 | 200 | 252 |
| Standard Length(m) | 1000 | 1000 | 1000 | 1000 | 1000 | 800 |
| Dia. Of Reel(mm) | 850 | 1000 | 1100 | 1250 | 1400 | 1440 |
| Total Weight(kg) | 294 | 454 | 642 | 886 | 1154 | 1368 |
