Gas / Coal / oil fired steam boiler High Pressure Steam Horizontal Steam Boiler
Price:
negotiated
MOQ:
1SET
Delivery Time:
Negotiate
Brand:
KANGWEI
Product Description
Gas / Coal / oil fired steam boiler High Pressure Steam Horizontal steam Boiler
1.Applications:
Marine /Industry
2.FACTORY ASSURANCE:
- One year parts warranty
- Spare parts available at ex-factory price
- Different voltage available
- 100% tested before delivery
- Minimum installation on site, electrical hook up, water pipe connection, steam pipe connection and drain only
- Skid-mounted complete system available
- Complete system in container available
3.SPECIFICATIONS:
|
Model Items |
WNS0.5-0.8-Y/Q | WNS0.75-0.8-Y/Q | WNS1-0.8-Y/Q | |
| Boiler horsepower | 32 HP | 48 HP | 63.8 HP | |
| Rated steam output | 500 KG/HOUR | 750 KG/HOUR | 1000 KG/HOUR | |
|
Maximum working pressure (manual reset) |
<0.8MPa / 116PSI | <0.8MPa / 116PSI | <0.8MPa / 116PSI | |
| Saturated steam temperature | <174°C | <174°C | <174°C | |
| Material of main body | 20# carbon steel | 20# carbon steel | 20# carbon steel | |
| Thickness of main body | 12mm | 14mm | 14mm | |
| Thermal efficiency | >88% | >88% | >88% | |
| Fuel consumption | 0# diesel | 34kg/h | 51kg/h | 68kg/h |
| Natural gas | 40.6Nm3/h | 60.9Nm3/h | 81.2Nm3/h | |
| LPG | 27.3kg/h | 41kg/h | 54.6kg/h | |
| Packing dimensions | L | 2680mm | 2680mm | 3982mm |
| W | 1660mm | 1760mm | 1917mm | |
| H | 1680mm | 1996mm | 2090mm | |
