SUS304 Anti - Static Air Shower Room For Semiconductor Factory 1300 * 1000 * 2180mm
SUS304 Anti-Static Air Shower room for Semiconductor factory
CUSTOMIZED DESIGN IS AVAILABLE
General Trade Information:
Brand: KELING
Model number: KL-AS1300P1 Series
Material: inside and outside is steel with power coated or inside is stainless steel304,
outside is steel with power coated.
OEM /ODM: Yes
Certificated: CE and Rosh
Start port: Guangzhou,Shenzhen
Delivery time: 8 working days after we get the deposit.
MOQ: 1sets
Country of Original: China
Payment term: T/T , L/C , Western union ,
Application: Semiconductor Clean room
Introduce:
In the electronics industry, the air shower room will blow the dust off the body, suck the dust into the high - efficiency air filter through the circulation system, and people usually think that dust adsorption is removed enough by air flow. But ignoring the gas friction will produce static electricity, and the greater the air flow , the greater the electricity generated, the charged particles in the space is easy to adsorb on the body after blowing dust.
Modern electronics industry demand is getting higher and higher for dust control, a the grade of dust free room is getting higher and higher. The practice of air shower room can no longer meet the requirements of modern electronic industry. In order to settle down this problem, the electrostatic eliminator can only be installed in the air shower, Using the air shower original high air speed from SUS304 nozzle send out charged ion produce by the electrostatic eliminator.
Once the countless charged ions are brought out quickly, not only the dust on the body can be blown away, but also the static electricity in the air and body can be eliminated, Only this way ,the dust particles will not be brought into the dust chamber.
Products Parameter:
| MODEL | KEL-AS1300P1 | KEL-AS1300P2 | KEL-AS1300P3 | |
|
External size (mm) (W*D*H) |
1300x1000x2180mm | 1300x2000x2180mm | 1300x3000x2180mm | |
|
Work zone (mm) (W*D*H) |
800x930x1910mm | 800x1930x1910mm | 800x2930x1910mm | |
| Persons per cycle | 1-2 person | 2-4 person | 3-6 person | |
|
Material (Option) |
1: External is steel with power coated, Internal is SUS304(T=1.0/1.2/1.5mm) 2: External is steel with power coated. Internal is SUS201(T=1.0/1.2/1.5mm) 3: Inside and outside is steel with power coated (T=1.0/1.2/1.5mm) |
|||
| Control system |
1: Control system with LED display for the shower time. 2: The shower time from 0-99second. (Adjustable) 3: Infrared ray inductor for inside personal shower automatic. 4: Three side blowing with Human voice prompt system. 5: Electrostatic Ion Wind Rod Copper for Neutralization of static electricity in short time, and ion air flow coverage a large area . 6: With CE remark. |
|||
| The power of fan |
380V/50HZ/0.75KW (2 set) |
380V/50HZ/0.75KW (4 sets) |
380V/50HZ/0.75KW (6sets) |
|
| Air flow of fan(m3/h) | 1500 | 1500 | 1500 | |
| Fan run (r/min) | 2800 | 2800 | 2800 | |
| Nozzle in stain less steel | 16 pcs | 32 pcs | 48pcs | |
| Wind speed(m/s) | >25m/s | |||
| Noise level(dB) | <75dB | |||
| Ion rod copper | 2 pcs | 4pcs | 6 pcs | |
| HEPA FILTER | Size(mm) |
630X630X80mm (2 sets) |
630X630X80mm (4 sets) |
630X630X80mm (6 sets) |
| Efficiency (%) | 99.995% @ 0.3um mini-pleats HEPA Air Filter | |||
| Air velocity | 1000(m3/h) | |||
| Initial resistance(pa) | <180pa | |||
| Pre-filter | Size(mm) | 775x380x17 | 775x380x17 | 775x380x17 |
| Efficiency (%) | 75% @ 0.5um | 75% @ 0.5um | 75% @ 0.5um | |
| G3 | G3 | G3 | ||
| resistance(pa) | <30 Pa | <30Pa | <30 Pa | |
| parameter | Power supply | 380v/50HZ 3P | 380v/50HZ 3P | 380v/50HZ 3P |
| Net power(kw) | 1.5 kw | 3kw | 4.5 kw | |
| packing size (mm) | 1350x1200x2250mm | 1350x2200x2250mm | 1350x3200x2250mm | |
| Packing material | Standard Export Poly wood Packing(Fumigant free material) | |||
| Weigh | 320kgs | 650kgs | 960kgs | |
Details:
