Customized Softwall Class 100 Pharmaceutical Clean Booth
Customized Turnkey Pharmaceutical Clean Booth/ Softwall Clean Room Free Design
Introduction
The modular cleanroom exterior is made of industrial-grade aluminum or stainless steel that is sturdy, resistant to rust, and does not collect dust.
The exterior is covered with anti-static material (often acrylic board) that is highly transparent, pliable and durable.
Fan Filter Units (FFU) employ a centrifugal fan, may run at a variety of different speeds, are easy to maintain, give off low vibration and noise levels, and are very durable.
Our modular cleanrooms only use lights approved for cleanroom applications. These lights do not produce any dust.
Parameter
| Parameter | Softwall PVC Type | Hardwall plexiclass Type |
| Cleanclass | Clean class 100-10,000 | |
| External dimension | Customized | |
| FFU | SUS stainless or Aluminium | Customized size and voltage |
| HEPA Filter | H14 HEPA Filter | |
| Frame material | SUS 304 Stainless | Aluminium |
| Air conditioner | Customized any temperature and humidity | |
|
Model |
KEL-SCB-1200 |
KEL-SCB-1500 |
KEL-SCB-1800 |
|
External Dimension (W×D×H)mm |
1200×1500×2300 |
1500×1500×2300 |
1800×1500×2300 |
|
Internal Work Zone (W×D×H)mm |
1100×1200×1900 |
1400×1200×1900 |
1700×1200×1900 |
|
Clean Class Level |
100class(U.S.Federal 209E Standard) |
||
|
Air Velocity |
0.3-0.5m/s |
0.3-0.5m/s |
0.3-0.5m/s |
|
Noise |
≤65dB |
≤65dB |
≤65dB |
|
Vibration Half Peak |
≤5um |
≤5um |
≤5um |
|
Light |
40W×2 |
40W×2 |
40W×2 |
|
Power Supply |
220V/50Hz |
220V/50Hz |
220V/50Hz |
|
Material |
Epoxy powder coated steel/full stainless steel |
||
