F5 F6 F7 F8 F9 Bag Type Pocket Air Filter Aluminum Frame Low Resistance

Name: F5 F6 F7 F8 F9 Bag Type Pocket Air Filter Aluminum Frame Low Resistance
Brand: KeLing Purification Technology Company

Price Negotiable

Price: negotiation

MOQ: 1 set

Delivery Time: 8-15 working day

Brand: KEL

Product Description

Aluminum Frame Low Resistance F5/F6/F7/F8/F9 Bag Type Air Filter/ Pocket Air Filter

Bag Type Air Filter Specification
Item	G3/G4/F5/F6/F7/F8/F9 Bag Type Air Filter
Bag Material	Non-woven /Synthetic Fiber/Glass fiber/Carbon fiber
Efficiency range	G3/G4/F5/F6/F7/F8/F9
Temperature	Max 80℃ (180℉)
Color	White,Orange,Green,Pink,Yellow,Black or Customized.
Bag Size	287592550, 592592550, 592592600 or Customized.
Frame Material	Galvanized, Aluminum alloy, Plastic box
Frame size	Customized
Initial resistance	≥45 Pa
Average Efficiency	45%,65%,85%,95%
Final Pressure	400Pa
Application	1.Heavy and metal industry 2.Chemical plants 3.Pharmaceutical and food industry 4.Paint spray plants 5.HVAC,FFU,AHU 6.Clean room MAU 7.Commercial&Industry ventilation system

Parameter

Class	Size(MM) HWD	Bags	Filtration Area	Reated Air Flow	Intial Resistance	Recommend Final Resistance
Class	Size(MM) HWD	Bags	Filtration Area	Reated Air Flow	Intial Resistance	Recommend Final Resistance
G4	287592550	3	1.86	1700	15	350
	592592550	5	3.12	3400	20
	592592600	6	3.78	3400	20
F5	287592550	3	2.12	1700	20	400
	592592550	5	3.66	3400	30
	592592600	6	4.40	3400	30
F6	287592550	3	2.12	1700	45	400
	592592550	5	3.66	3400	80
	592592600	6	4.40	3400	80
F7	287592550	3	2.80	1700	100	400
	592592550	5	4.78	3400	125
	592592600	6	5.78	3400	125
F8	287592550	3	2.80	1700	110	450
	592592550	5	4.78	3400	130
	592592600	6	5.78	3400	130

Feature

1.Large dust capacity and stable performance
2.Large air volume, low resistance and high efficiency
3.Long service life
4.Washable and reusable
5.Economical and cost-effective
6.Size customized
