PET Bottle Washing Filling Capping 3 in1 Monobloc Machine , Automatic Water Filling System

PET Bottle Washing Filling Capping 3 in1 Monobloc Machine , Automatic Water Filling System

bottle filling system

1. BRGF Series

2. filling speed :6000-12000bph @500ml

3. Suitable bottle size :250ml-1500ml

glass bottle filliing mahcine production line photos

Description

bottle filling system

The machine is based on the introduction of foreign technology,combined with our years of manufacturing experience .the machine

combines Washing,filling and capping ,with scientific and rationaldesign,beautiful shape.it is easy in maintenance ,with automation.this

machine is mainly used for water filling .

1. Rinsing empty bottle, filling, and capping functions are integrated in one system, fully automatic synchronized working.

2. Bottle travels on neck to neck from in-feed till out-feed resulting scratch free movement of bottle.

3. Pressure filling nozzles deliver fast, efficient, and accurate dispensing with minimal dripping and leakage.

4. No Bottle No Filling, no caps no capping, no caps auto stops

5. When bottle jam auto stop, machine accident auto stop

6. Open the window when machine running, machine auto paused

7. Heavy duty stainless steel filling pump & rinsing pump

8. Food grade 316L or 304stainless steel contact parts, smooth & fine polish,no dead angles

9. Adopted first class component from Mitsubishi, OMRON, SIEMEN, With PLC, invertors control, touch screen, sensor, switch and other electric parts.

10. Machine and cable arrangement designed according to CE standard and all safety standard

Applications:

The series equipment is used in production liquor, wine, soy vinegar etc.

Pet bottle and glass bottle

Screw capping and press capping cap

Specifications:

Competitive Advantage:

1. The BRGF series 3-in-1 Glass Bottle Filling Machine, capacity is in 3000-12000 bottles per hour.

2. It is widely used in Wine, Liquor , Alcohol drinks, Vodka , Whiskey, Agave, Vinegar etc.

3. Apply to kinds of 0.18L-2LRound / Square / Flat Glass Bottle.

3. The lid can be crown cap or aluminum screw-cap, plastic cap, twist-off cap, etc.
