Edible Oil / Cooking Oil Liquid Bottle Filling Machine for PET Botte 0.75kw - 2.2kw
Edible Oil / Cooking Oil Liquid Bottle Filling Machine for PET Botte 0.75kw - 2.2kw
Quick Detail:
1: Liquid detergent filling machine
2: High viscosity filling machine
3: Long useful life
4: Low maintains
Description:
Liquid bottle filling machine for cooking oil
1. Liquid bottle filling machine for cooking oil is widely used for the filling of low-viscous liquids, like shampoo, juice, Liquid Detergent, liquid soap etc.
2. Adopting piston-type measuring pump to fill, with high filling precision. PLC system to control, with highly-automation
3. All parts contacting liquids are made of top-quality SUS316/SUS304, others are all SUS304, delicate in design, durable.
4. Easy to dismantle, clean & disinfect.
5. Linear bottles in & out, Convenient to change bottles of different sizes & filling dosage.
6. Filling nozzles are equipped with anti-drip device, ensuring no foam, no drip & no leakage.
7. Can meet different capacity requirements, ranging from 1000-5000BPH, from 10-5000ml dosage.
Applications:
This machine is suitable for suitable for fill all kinds of liquid detergents, such as dish washing, toliet filling machine, kitchen ware detergent, tile floor detergent etc.
Specifications:
|
Item |
ZYZ-4 |
ZYZ-8 |
ZYZ-12 |
ZYZ-16 |
ZYZ-20 |
|
Filling nozzle |
4 |
8 |
12 |
16 |
20 |
|
Filling scope |
20-5000ml |
20-500ml |
|||
|
Idea filing range |
20-100ml 50-250ml100-500ml200ml-1000ml500-2500ml1000-5000ml |
||||
|
capacity
(100ml) |
40-60 |
60-80 |
70-90 |
80-100 |
90-120(1 line) |
|
Filling precision |
20-1000ml: ≤±1% 1000-5000ml: ≤±0.5% |
||||
|
Air pressure |
0.4~0.6MPa |
||||
|
Voltage |
220V 50/60Hz |
||||
|
Power |
0.75kw |
0.75kw |
1.2kw |
2.2kw |
2.2kw |
|
Noise |
≤50dB |
||||
|
N.W. |
500kg |
800 kg |
1000 kg |
1300kg |
1500kg |
|
Dimension (mm) |
1300×1000×1800 |
1600×1000×1800 |
1900×1000×1800 |
2300×1000×1800 |
2600×1000×1800 |
Competitive Advantage:
Liquid bottle filling machine for cooking oil
long service life
low maintenance rate
factory price
CE, meet GMP requirement
