Glass Bottle Energy Drink Filling Machinery , High Speed Large Gravity Filling Machine
Glass Bottle Energy Drink Filling Machinery , High Speed Large Gravity Filling Machine
Introduction:
1. Machine include: bottle washing, energy drink filling, cap sealing three sections.
2. Bottle: PET or Glass bottle 200ml to 3000ml
3. Cap: plastic screw cap, or pressing cap, crown cap etc...
4. Juice: hot filling tea.
5. Production capacity: from 2000 to 30000 bottles/hour 500ml, or according to your inquiry.
6. Machine certification: ISO, SGS, CE, GMC
7. We can provide energy drink filling machine include: energy drink mixing, sterilization, storage, bottle making, bottle washing, filling, cap sealing, labeling, printing, packing and conveyor system etc... according to your bottles and caps.
8. We can send technicians go to your factory to make machine installation and training.
Usage:
This machine is special used for grainy juice, and pulp juice bottling process.
It is consists of washing-pulp filling-juice filling-capping 4 parts (or separate)
Meanwhile, the pulp filler is piston filling type, It widely used for sauce and oil and other viscous material.
The filling capacity is 200ml-2000ml adjustable.
Energy drink filling machine characteristics:
1. Using the air sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change of the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
7. Equipped with a constant temperature system, temperature controlled and circumfluenting automatically.
Technical parameter:
| Model | Number of washing filling and capping |
Production capacity Bottle per hour(0.5L) |
Applicable bottle specifications (mm) | Power(kw) | Dimension(mm) |
| RCGF14/12/5 | 14, 12, 5 | 2000-3000 |
0.25L-2L 50-108 mm H=170-340mm |
3.58 | 2100x1400x2500 |
| RCGF18/18/6 | 18, 18, 6 | 4000-6000 | 7.61 | 2460x1720x2650 | |
| RCGF24/24/8 | 24, 24, 8 | 6000-8000 | 8.2 | 3100x2100x2650 | |
| RCGF32/32/8 | 32, 32, 8 | 10000-12000 | 9.18 | 3500x2500x2650 | |
| RCGF40/40/10 | 40, 40, 10 | 13000-15000 | 10.28 | 4600x1800x2650 | |
| RCGF50/50/12 | 50, 50, 12 | 16000-18000 | 11.28 | 5200x4500x3400 | |
| RCGF60/60/15 | 60, 60, 15 | 20000-22000 | 11.28 | 6500x4500x3400 |
Juice filling machine photos:
Certifications:
Container loading:
