Mango Pulp / Puree Mango Juice Filling Machine Capacity 5000 Bottles / Hour
Mango Pulp/ Puree Mango Juice Filling Machine Capacity 5000 Bottles / Hour
Quick Detail:
1. Product: pulp / puree mango juice, orange juice etc.
2. Suitable bottle: 0.25-2.5L PET bottle or Glass bottle
3. Productivity: 2000-20000bph
4. Authentication: ISO,CE,SGS, GMC, UL
5. we can provide: filling labeing packing mixing water purification etc.
Product detail:
This machine is special used for grainy juice, and pulp juice bottling process.
It is consists of washing-pulp filling-juice filling-capping 4 parts (or separate)
Meanwhile, the pulp filler is piston filling type, It widely used for sauce and oil and other viscous material.
The filling capacity is 200ml-2000ml adjustable.
Technical Data:
| Model | Number of washing filling and capping | Production capacity Bottle per hour(0.5L) |
Applicable bottle specifications (mm) | Power(kw) | Dimension(mm) |
| RCGGF18/12/16/5 | 18, 12, 16, 5 | 5000-6000 | 0.25L-2L 50-108 mm H=170-340mm |
7.68 | 3500x1400x2500 |
| RCGGF24/16/24/8 | 24, 16, 24, 6 | 8000-10000 | 8.68 | 4460x1720x2650 | |
| RCGGF32/18/32/8 | 32, 18, 32, 8 | 10000-12000 | 10.18 | 5100x2100x2650 | |
| RCGGF40/24/40/10 | 40, 24, 40, 10 | 15000-16000 | 12.28 | 6100x4500x3400 |
