CGF series 5L Water Bottle Washing-filling-capping Machine 3-in-1 unit


CGF series 5L Water Bottle Washing-filling-capping Machine 3-in-1 unit

Quick Detail:

1. Product: pure drinking water
2. Suitable bottle: 3-10L plastic big bottle
3. Productivity: 2000-3000bph(5L)
4. Authentication: ISO,CE,SGS

Description:

Drinking pure water bottling machine for PET bottle rinsing-filling-capping is mainly used in the water filling operations. The three functions of bottle wash, fill and seal are composed in one body of the machine. The whole process is automatic.
1. Direct connection technology between air conveyor and in-feeding starwheel is applied to replace in-feeding screw and conveying chain to ease bottle changing process with only to change few parts. Newly-designed bottle-separating grippers are assembled to starwheel.
2. We adopts Neck-hanging technology in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily, without equipment height adjustment, only few parts need to be adjusted
3. Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4. High-speed filling valves with big flow volume are equipped with PLC control system.
5. Splint of starwheel using twist descending way to simplify the process of bottle-size-changing. Only need to change arch board and starwheel, within ten minutes


Applications:

The Drinking pure water bottling machine for PET bottle rinsing-filling-capping is mainly used for washing, filling and capping PET bottle which can fill non-carbonated drinks. Such as mineral water, pure water, wine and so on. Bottle washing, filling and capping are achieved in one machine. The contact time is shorten between material and the outside. And improved the health conditions, production capacity and economic benefits.

It adopts gravity filling technology, automaitc cap pickup, agenetic force capping, and the capping force adjustable.


Specifications:

Competitive Advantage:

1. Using the wind sent access, with clamp hanging the bottle neck; which can keep the bottle shape and high-speed.
2. Bottles transmission of the water filling machine adopts clip bottleneck technology, clean and fast.
3. Filling uses liquid cylinder feeding structure, filling valve uses new normal pressure filling, ensure the filling correct and stable,
4. Spiraling decline when output bottle, transform bottle no need to adjust the height of conveyor chains. Cap automatically.
5. Host adopts advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
