Automatic Glass Water Bottling Machine , 4000BPH Rotary Washing Machine
Automatic Glass Water Bottling Machine , 4000BPH Rotary Washing Machine
Quick Deatil:
1. Kind of bottle: plastic/glass bottle
2. Bottle diameter: Min. 30mm Max.80mm
3. Bottle height used: 80~300mm
Description:
The rotary bottle washing machine is mostly used for rinse glass and plastic bottle, which is able to pick and reverse bottle, water rinsing,
reverse upright bottle, and auto out-feed to conveyor, it is fully automatic to finish track rinsing.
Technical Parameters:
1. Kind of bottle: Various kinds of plastic/glass bottle
2. Bottle diameter: Min. Ø 30mm Max. Ø 80mm
3. Bottle height used: 80~300mm
4. Neck size: Ø 15~35mm
5. Nos. Of Rinsing head: 12
6. Speed Max.: 80bpm
7. Power: 380V 50/60Hz 1.5kw
8. Compress air require: 100L/min, 4~6bar
9. Machine weight: 300kgs
| Model | ZCP-12 | ZCP-18 | ZCP-24 |
| production(b/h) | 2000-3000 | 4000-6000 | 6000-8000 |
| Diameter of bottle(mm) | 62-100 | 60-100 | 60-100 |
| Hight of bottle (mm) | 160-320 | 160-320 | 160-320 |
| Pover(kw) | 0.75 | 1.45 | 1.45 |
| Ocerall diminsions(mm) | 1170*1120*1800 | 1530*1340*1800 | 1600*1450*1800 |
| Weight(kg) | 300 | 500 | 800 |
Competitive Advantages
1, high quality and competitive price
2, work stable
3, good sales-service
