SS304 PET Bottled Juice Filling Plant Full Automatic 0.25 - 2L

SS304 PET Bottled Juice Filling Plant Full Automatic 0.25 - 2L

Specifications

PET Bottled Juice bottling line
1. Juice preparation system
2. Filling system
3. Packing system
4. CIP


PET bottled juice bottling line:

The series equipment are used for the production of green tea,black tea and fruit juice.It integrates bottle washing ,filling,capping together.The edsign is scientific and reasonable.Its appearance is beautiful, operation and maintenance is convenient.

Features:

1. High speed filling valve, guarantees liquid has precise level and no waste is incurred

2. The capping heads apply constant magnetic torque device to secure capping quality  and prevent damage to the bottle cap.

3.  The control system has the function of control producing speed, cap shortage detection, bottle block auto stop and production counting.

4.  The advanced programmed controller (PLC) is adopted to control the machine to run automatically.

Technical parameter:

Model: RCGF40-40-12

Washing heads: 40

Filling heads: 40

Capping heads: 12

Production capacity: 17,000-18,000B/H (basis on 500ml bottle)

Filling precision: ≤±5mm (liquid level)

Feedback consumption: ≤10%

Suitable bottle diameter: φ50-φ120mm

Suitable bottle height: 150-340mm

Suitable cap type: plastic screw cap

Gas source pressure: 0.7Mpa

Gas consumption: 0.5m3/min

Total power: 11Kw

Total weight: 9000Kg

Overall dimension: 4720×3550×2750mm
