5000-6000BPH Automatic Bottle Filling Machine Cubilose Rinser Filler Capper

Price Negotiable
MOQ: 1
Delivery Time: 40 days
Brand: HS-Filling
Product Description



5000-6000BPH Automatic Bottle Filling Machine Cubilose Rinser Filler Capper

 Automatic 3-in-1  Edible Bird's Nest filling machine piston type filling machine
1. Product:  Edible Bird's Nest
2. Suitable bottle: 100ml-2000 ml glass jar
3. Productivity: 2000-18000bph
4. Authentication: ISO,CE,SGS

Applications:

This Automatic 3-in-1  Edible Bird's Nest filling machine piston type filling machine is an automatic filling and capping machine. it adopt piston filling type,it could be applicable for all kinds of  Edible Bird's Nest , oil,fruit &vegetable sauce(with or without solid piece)


Description:


Suitable filling material
This Automatic 3-in-1  Edible Bird's Nest filling machine piston type filling machine adopts magnetic drive pump, which is suitable for all kind liquid materials, with high filling speed and high filling precision.
 Main component:
All use word-class famous brand. All the material is stainless steel 304, PLC control, Human-computer touch screen and Cylinder Airtac (Taiwan)Photo sensor Omron (Japan)
 Controlling system
The machine adopts full-auto PLC and human-computer touch screen control system. For different volumes adjustment, just need to input the volumes in computer.
 Bottle position correct device
To ensure the bottles and filling nozzles are in the correct position, we add a special bottles position device to make the whole filling process smooth and stable. No bottle no filling.
 Filling nozzle
To avoid, it adopts diving filling.


Specifications:



Model

Number of washing filling and capping

Production capacity
Bottle per hour(0.5L)

Applicable bottle specifications (mm)

Power(kw)

Dimension(mm)

GZS12/5

12, 5

2000-3000

0.25L-2L
50-108 mm
H=170-340mm

3.58

2100x1400x2300

GZS16/6

16, 5

4000-5000

3.58

2460x1720x2350

GZS18/6

18, 6

6000-7000

4.68

2800x2100x2350

GZS24/8

24, 8

9000-10000

4.68

2900x2500x2350

GZS32/10

32, 10

12000-14000

6.58

3100x2800x2350

GZS40/12

40,12

15000-18000

6.58

3500x3100x2350






Machine video link
https://www.youtube.com/channel/UC115UgWksIYd7CLUGSRhQSg/videos
