220V 380V Famous Brand Compressor Cold Storage Room For Supermarket
Fruit and Vegetable Cold Room Manufacturers Compressor Condenser Equipment
Cold Storage Room Main Features:
- Neat appearance: The insulation panel and framework are available in different colors which are to be elected in satisfactory harmony with various styles of buildings.
- Insulation: Polyurethane or polystyrene material with low thermal conductivity and high strength, achieving good insulation performance.
- Modular insulation panels and integrated design. Convenient installation and short construction period.
- High hygienic conditions of food storage up to the standards.
- Durable building structure, super quality material
we Can delivery in 10~15days.
|
Composition of cold room
|
|||
|
Cold room panel
|
Surface material
|
Kraft paper, color steel plate, stainless steel plate, aluminum plate, galvanized sheet
|
|
|
Thickness of cold room panel
|
50mm,75mm,100mm,120mm,150mm,200mm
|
||
|
Width of cold room panel
|
≤960mm,≤1000mm
|
||
|
Length of cold room panel
|
≤11800mm
|
||
|
cold room door
|
Electric translational door ,Manual translation door,Half buried door ,Fully buried door, Free-style door,Clean door.
|
||
|
Condensing unit
|
Famous Brand, Copeland, Maneurop, Fusheng
|
||
|
Evaporator
|
KELTESS air-cooler
|
||
|
Other accessories
|
world-famous brands, like Danfoss, Castle, Every Control, Siemens, LG
|
||
| Cold storage room | ||||
| Classification | keep fresh | Cold storage | low temperature | frozen |
| temperature(℃) | 0 ~ 5 | -15 ~ -18 | -22 ~ -25 | -30 |
| Power(kw) | 80 | |||
| The capacity is according to the size of the cold storage room. | ||||
| Size | small | Small and medium | Large and medium | Large |
| Capacity(t) | Below 1000 | 1000-5000 | 5000-10000 | Above 10000 |
| We can customize the Refrigeration house according to your needs. | ||||
What is the Specification of our cold room?
| Product Name | Cold Storage Room Refrigeration Unit |
| Model No. | GHC-40 |
| Temprature | 0℃(32℉) ~ 15℃(59℉) / -25℃(-13℉) ~ -18℃(-0.4℉) / -40℃(-40℉) ~ -30℃(-22℉) |
| Cooling System | Air Cooling |
| Compressor | Copeland/ Famous Brand |
| Voltage | 220-380V / 50-60Hz |
| Refrigerant | R404a |
| Thickness | 50mm / 75mm / 100mm / 120mm / 150mm / 200mm |
| Installation | With drawing |
| Plug | Various Styles |
| OEM / ODM | Yes |
Easily assembled cold storage room polyurethane panel:
The joint of the PVC polyurethane insulation prefab cold storage room panel are made with tongue and groove edges and are locked together with cam lock design fasteners. The prefabrication cold room panel and other refrigeration system parts of the walk-in cooler and walk-in freezer chamber are shipped by knocked down uninstalled method to customers. This saves much freight cost for the modular cold-room transportation. When the unassembled cold room arrives, users can easily assemble and install the cold rooms by themselves. Or when users want to move the walk-in cooler or walk-in freezer to another place, the cold room panels of the mobile cold room chamber can be easily disassembled with a hex wrench and re-installed. Cold storage room installation & un-installation is just so simple!
| Thickness of polyurethane panel | Application temperature |
| 50mm | Temperature 5°C or above |
| 75mm | Temperature -5°C or above |
| 100mm | Temperature -18°C or above |
| 120mm | Temperature -25°C or above |
| 150mm | Temperature -35°C or above |
| 200mm | Temperature -45°C or above |
Notes: According to your requirements, the manufacturer can reasonably configure the materials that suit you, the size and thickness of the panels.
- Material: polyurethane (PU), metal sheet.
- Density of PU: 42kg/ m3
- Metal sheet:according to requirements
Cold storage room images:
| Company Profile |
Guangdong Green&health Intelligence Cold Chain Technology Co., Ltd is a professional manufacturer with more than 10 years experience in the R&D of commercial refrigeration equipment. Covering an area of 50,000 square meters , and the registered capital is 10 million RMB, now there are more than 300 employees including 50 senior technical managerial personnel. Green&Health is dedicated to be the most influential and professional intelligent cold chain production base in southern China!
| Workshop & Showroom |
| Our Certificates |
| Payment & Shipping |
 |
|
| PAYMENT: Standard payment terms: 30% T/T deposit, balance against the copy of B/L More payment terms could be provided (LC/DA/DP PAYPAL WESTERN UNION) |
SHIPPING: Delivery time: 15 days after deposit payment received (based on order quantity) Packing: Plywood box or customized packing as your request. |
