Hydraulic Automatic low noise Stator Winding Coil Pre-Forming Machine

Quick Detail:

Specifications :

Description:

The semi automatic Stator Winding Pre-forming Machine is driven by hydraulic system; PLC programming; tooling expansion slice makes the first coli and inter-phase insulation paper in slot adjacent, leaving enough space for second insertion and ensurethe quality of successive coil insertion; apply to multi-layer stator winding insertion.


Applications:

After inserting the first winding, use this machine to form the winding into specified dimension, so that the next winding inserting could be easier and convenient. It is used for stator which meet the specification of below.

Competitive advantages:

Fast speed .

low noise;

simple operation and easy tooling change.

PLC and touch screen control.


Picture show

Machine handling

1. Use forklift for load and unload, pay attention to machine barycenter, shovel from the base part of machine bottom.
2. Please use hoisting equipment with enough capacity for machine handling, otherwise it will result in machine fall, further causing accidents like machine breakdown even injuries and deaths.
3. Remove all processed workpieces or unprocessed workpieces before moving the machine, check and make sure all sorts of fasteners is tight.
