Two Fence 4.5m Boom Length DC24V Brushless DC Motor Parking Barrier
Price:
negociate
MOQ:
1 set
Delivery Time:
3-5 working days
Brand:
WEJOIN
Product Description
Two fence 4.5m boom length DC24V brushless DC motor parking barrier
Boom Barrier Basic Features:
1. Safe---the barrier will automatically go back when it meet obstacles during closing.
2. DC Brushless motor is more powerful and no maintenance.
3. Boom can be chosen from 3 meters to 6 meters, and barrier closing time is also arranged from 1.5 seconds to 6 seconds.
4. All the operation process is soft without any noise and shaking.
5. Infrared photocell interface, Loop detector interface and IC system interface are reserved for the other functions.
6. Green light and red light are used inside to indicate the position of the boom.
7. Fan cooling machine reduces the motor temperature by high frequency using, and never get over-heated. Unique temperature calefaction design for low temperature using, prevent freezing in cold weather.
8. Exactitude aluminum alloy die-casting motor base reduces the noise and joint abrasion to prolong the barrier gate working life.
Intelligent Barrier Technical Data:
|
Input Voltage |
AC220V±10%, AC110V±10% |
|||
|
Frequency |
50/60HZ |
|||
|
Max Motor Power |
200W |
|||
|
Max Motor Speed |
40r/min |
|||
|
Working Temperature |
-35°C∼+85°C |
|||
|
Enclosure Rating |
IP54 |
|||
|
MTBF |
2,500,000 times |
|||
|
Net Weight |
40KGS |
|||
|
Gross Weight |
45KGS |
|||
Optional Barrier Housing:
Sturdy and strong housing 2.5 mm thickness mild steel, Housing is polished, phosphorized and further finished with plastic coating to ensure long lasting bright colors)
Optional Colors:
We have the following 3 kinds of colors, and you can choose by your request.
Tell me the code of the color on the color board (eg: black is ECH200). And you can also adopt our standard color.
