Heavy Duty 6m Telescopic Straight Boom Car Park Barrier Gate AC Motor for Parking Spaces
Heavy Duty 6m Telescopic Straight Boom Car Park Barrier Gate AC Motor for Parking Spaces
Automatic Barrier Functions and Features
1. The barrier gate can be conveniently operated using a remote control. This remote - control functionality offers users the flexibility to open and close the gate from a distance, enhancing the convenience of access control. Whether for security personnel or authorized vehicle owners, the remote control allows for easy management of the gate, improving the overall efficiency of the access control system.
2. There is an interface provided for the traffic light, with a dry contact output. It is important to ensure that the traffic light used with this interface has a current draw of less than 10A. This interface allows for the synchronization of the barrier gate's operation with traffic lights, optimizing the flow of traffic and enhancing overall safety at the access point.
3. The barrier gate offers a signal of its limit status for the car parking system, with outputs for COM (common), NC (normally closed), and NO (normally open). These status signals can be used by the parking system to monitor the position of the barrier gate accurately, enabling better control and management of the parking facility. For example, the system can know if the gate is fully open, fully closed, or in an intermediate position.
Barrier Gate Technical Data
1. Working voltage: 220V士10%,50HZ or 110V 士10%,60HZ
2. Rated Power: 200W
3. Working temperature (motor and control panel): -35°C + 80°C
4. Humidity:≤90% RH
5. Distance of remote control: 100M>L≥30M in the open place
Boom Barrier Spring Selection Table
|
Boom Type |
Boom Length (Meter: M) |
Spring Diameter Φ (mm) |
|
Straight Boom without Rubber |
6≥L≥4.8 |
Φ5.5+Φ4.5 |
|
4.8>L≥3.5 |
Φ5.5 |
|
|
3.5>L≥2.5 |
Φ4.5 |
|
|
Straight Boom with Rubber |
6≥L>5.3 |
Φ6.8+Φ4.5 |
|
5.3≥L≥4.3 |
Φ5.5+Φ4.5 |
|
|
4.3>L≥3.3 |
Φ4.5+Φ4.5 |
|
|
3.2≥L |
Φ4.5 |
|
|
Articulated Boom |
5≥L>4.3 |
Φ5.5+Φ4.5 |
|
4.3>L≥3 |
Φ4.5+Φ4.5 |
|
|
3>L |
Φ4.5 |
|
|
Fence Boom, Two - levels |
4.5≥L≥4.3 |
Φ6.8+Φ5.5 |
|
4.3>L≥3.8 |
Φ6.0+Φ5.5 |
|
|
3.8>L≥3 |
Φ5.5+Φ4.5 |
|
|
3>L |
Φ4.5+Φ4.5 |
|
|
Fence Boom, Three - levels |
4≥L≥3.8 |
Φ6.8+Φ5.5 |
|
3.8>L≥3.3 |
Φ6.0+Φ5.5 |
|
|
3.3>L≥2.5 |
Φ5.5+Φ4.5 |
Boom Barrier Common Malfunctions and Solutions
- The barrier arm rise up automatically when falling down at 45 degree.
If using digital limit, please check DIP “3s/6s switch button”, whether the DIP is same as the speed of the barrier.
- Barrier arm stop after moving a little when falling down or rising up.
Check up if the limit switch interface is connected well.
- Barrier arm is not in vertical or horizontal limit position.
1. For Blade type limit, check up the photo electricity limit switch.
2. Check up DIP of up angle is adjusted to the end.
3. Check up the connection rod, and vertical and horizontal position of the barrier arm.
