Heavy Duty Remote Control Anti-collision 6m Telescopic Straight Boom Car Park Barrier Gate

Barrier Gate Technical Data

1. Working voltage: 220V士10%,50HZ or 110V 士10%,60HZ

2. Rated Power: 200W

3. Working temperature (motor and control panel): -35°C + 80°C

4. Humidity:≤90% RH

5. Distance of remote control: 100M>L≥30M in the open place

Boom Barrier Spring Selection Table

Boom Barrier Common Malfunctions and Solutions

- The barrier arm rise up automatically when falling down at 45 degree.

If using digital limit, please check DIP “3s/6s switch button”, whether the DIP is same as the speed of the barrier.

- Barrier arm stop after moving a little when falling down or rising up.

Check up if the limit switch interface is connected well.

- Barrier arm is not in vertical or horizontal limit position.

1. For Blade type limit, check up the photo electricity limit switch.

2. Check up DIP of up angle is adjusted to the end.

3. Check up the connection rod, and vertical and horizontal position of the barrier arm.

Automatic Barrier Functions and Features

1. Open the barrier gate by the motor wheel when power is off and automatically reset when power is on.

2. Balanced boom running with a motor transmission of cranks and shafts.

3. Remote control to operate the barrier gate.

4. Auto-reverse when boom meets obstruction (only for barrier using the digital limit device)

5. Infrared photocells interface is available (need to install photocell device).

6. Loop detector interface is available (need to install loop detector).

7. Well-integrated with car parking system equipment, with wire control (must be dry contact signal).
