1800KG Heavy duty sliding gate motor manufacturers with gear rack

Function and Features
1. Integrated structure of the mechanic and electron. No need to install other controllers.
2. Electronic soft-start.
3. Automatically restraining when meets obstacle.
4. Crash proof and automatically restraining socket.

5. Crash proof (photocell).
6. Alarm light socket.
7. Line control and Remote control are optional.
8. Intelligent automatic heating function.
9. Automatically increase the temperature when the temperature is below 0 degree.

Motor Data

Model: KMP202

Voltage: 220V±10%, 110V±10%

Frequency: 50/60Hz

Current: 2.7A, 5.8A

Motor voltage: AC 220V/110V

Capacitor: (220V) 20µF, 60µF+14µF

Power: 350W

Torque: 35nm

Motor number: M=4

Motor speed: 1350rpm, 1620rpm

Gear speed: 58.8rpm, 70.2rpm

Travel speed: 11m/min, 13.2m/min

Working temperature: -40°c~ 55°c

Overload protection temperature: 130

Relative humidity: ≤90%

Motor making technique: die casting aluminum alloy

Manual Release: yes

Remote distance: >30m

Product weight, approx: 10.19kg, 10.25kg

Max, weight of gate: 1800kg

Electronic Data

Motor base and it's installation

1. Motor base installation: set the installation position of the base tray according to the size of the motor and the height of the installation position of the gear rack. Then Embed the bolts in advanced or use the expansion bolts to embed the base into the cement foundation.
2. If the gear rack has already been installed, fix the motor to th base and turn the clutch with the clutch key to the off position, then make the gear of the motor suit right to the gear rack, then the position of the base can be set. Take off the motor and fix the base.
